- Page 1 Height Measurement USER MANUAL HM80D Digital Infant Stadiometer Please keep the instruction manual at hand and follow instruction for use.
-
Page 2: Table Of Contents
CONTENTS Ⅰ. SAFETY NOTES ..............2 Ⅱ. EMC GUIDANCE AND MANUFACTURER'S DECLARATION ..2 III. KEY FUNCTION ..............2 IV. SPECIFICATION ..............2 V. INSTALL BATTERY ..............2 VI. TROUBLE SHOOTING ............2 VII. CALIBRATION ..............2 VIII. HOW TO MEASURE ............2 IX. - Page 3 Explanation of Text/Symbols on Device Label/Packaging Text/Symbol Meaning Caution, consult accompanying documents before use Separate collection for waste of electrical and electronic equipment, in accordance with Directive 2002/96/EC. Do not dispose of device with everyday waste Name and address of device manufacturer, and year/country of manufacture Carefully read user manual before installation and usage, and follow instructions for use.
- Page 4 Device complies with EC directives (verified models only) M: Conformity label in compliance with Directive 2014/31/EU for non-automatic weighing instruments 20: Year in which conformity verification was performed and the CE label was applied. (ex: 16=2016) 0122: Identifier for metrology Notified Body Device is a Class III scale in compliance with Directive 2014/31/EU (verified models only) Name and address of entity importing device (if...
-
Page 5: Copyright Notice
Copyright© Charder Electronic Co., Ltd. All rights reserved. This user manual is protected by international copyright law. All content is licensed, and usage is subject to written authorization from Charder Electronic Co., Ltd. (hereinafter Charder) Charder is not liable for any damage caused by a failure to adhere to requirements stated in this manual. -
Page 6: Ⅰ. Safety Notes
Ⅰ. Safety Notes General Information Thank you for choosing this Charder Medical device. It is designed to be easy and straightforward to operate, but if you encounter any problems not addressed in this manual, please contact your local Charder service partner.Before beginning operation of the device, please read this user... -
Page 7: Intended User Profile
Intended user profile (a) At least 20 years old (b) Minimum knowledge: - To be able to read at a high-school level and understand Arabic numerals (e.g. 1, 2, 3, 4...) - Basic hygiene knowledge - Trained in device's operation - Read the instruction manual (c) Language - Able to read the language of instruction manual and on-... -
Page 8: Using Batteries
If you have any problem, please contact your local CHARDER MEDICAL service partner. Cleaning Only the original adapter should be used with the device. Using an adapter other than the one provided by Charder may cause malfunction Do not touch the power supply with wet hands. -
Page 9: Maintenance
Maintenance Please contact your local Charder distributor for regular maintenance and calibration, regular checking of accuracy is recommended; frequency to be determined by level of use and state of device. Warranty A two-year warranty from date of delivery applies to defects attributable to poor materials or workmanship. -
Page 10: Ⅱ. Emc Guidance And Manufacturer's Declaration
Ⅱ. EMC Guidance and Manufacturer's Declaration Guidance and manufacturer’s declaration-electromagnetic emissions The product isintended for use in the electromagnetic environment specified below. The customer or the user of the product should assure that it is used in such an environment. Emission test Compliance Electromagnetic... - Page 11 Guidance and manufacturer’s declaration-electromagnetic immunity Theproduct is intended for use in the electromagnetic environment specified below. The customer or the user of the product should assure that is used in such and environment. Immunity IEC 60601 test Compliance Electromagnetic test level level environment-guidance...
- Page 12 Recommended separation distance between portable and mobile RF communications equipment and the product The product is intended for use in an electromagnetic environment in which radiated RF disturbances are controlled. The customer or the user of the product can help preventelectromagnetic interference by maintaining a minimum distance between portable and mobile RF communications equipment (transmitters) and the product as recommended below, according to the maximumoutput power of the communications equipment.
-
Page 13: Key Function
RESET RESET key is for user to calibrate false reading. Slide right feet piece to the left at length of 35cm. Press RESET key to calibrate HM80D. LCD will display 35.0cm which means HM80D has been well calibrated. IV. Specification... -
Page 14: Install Battery
Items Spec. Qty. HM80D digital baby length User manual IN-1072 [8056] Battery AAA 1.5V Bracket set for baby tray SS-5611 (option) Bracket set for MS2400 SS-5621 (option) Bracket set for MS5900 SS-6111 (option) V. Install battery Installing battery AAA 1.5V x 2 in battery housing next to LCD display... -
Page 15: Trouble Shooting
VI. Trouble shooting 1. If feet piece is loose please re-assemble feet piece as below. VII. Calibration 2. If the reading shows error, please follow RESET procedure for calibration. 1. Installing battery. 2. Press ON/OFF to switch on LCD. 3. Sliding feet piece left to the end. 4. Press RESET button to calibrate at 35.0cm. -
Page 16: How To Measure
VIII. How to measure 1. Lightly slide feet piece left against the sole of baby. 2. Sliding feet piece left till it touches the sole of baby. 3. The LCD is displaying length of baby. 4. Press HOLD button to memorize the reading of length. 5. -
Page 17: Assembly With Removable Baby Tray
IX. Assembly with removable baby tray A. Fix bracket on the tray with two screws. SS-5611 bracket B. Assemble HM80D with scale together. - Page 18 C. Press the buckle to secure HM80D is welled installed. D. Assemble completed.
- Page 19 1. Assembly with MS5900 baby scale A. Remove bracket holder cover. B. Take off bracket holder cover.
- Page 20 C. Fixing bracket with two screws. SS-6111 bracket D. Assemble baby height rod with the bracket carefully until click. FOR HM 80M & HM80D Slide...
- Page 21 E. Install the bracket holder cover. HM 80D HM 80M...
-
Page 22: Assembly With Ms2400 Baby Scale
X. Assembly with MS2400 baby scale A. Place the bracket and tighten the screw with screw driver. Rubber head SS-5621 bracket Fix the bracket here for the scale with rubber head pad Fix the bracket here for the scale without rubber head pad... - Page 23 B. Assemble baby height rod with the bracket carefully until click.
-
Page 24: Manufacturer's Declaration Of Conformity
XI. Manufacturer’s Declaration of Conformity This product has been manufactured in accordance with the harmonized European standards, following the provisions of the below stated directives: (EU) 2017/745 Regulation on Medical Devices 2014/31/EU Non-automatic Weighing Instruments Directive (OIML models only) RoHS Directive 2011/65/EU and Delegated Directive (EU) 2015/863 Radio Equipment Directive 2014/53/EU (applicable if wireless module is used) Part 15 of the Federal Communications Statement Rules...
