- Page 1 Height measurement USER MANUAL HM200U Ultrasonic Stadiometer Please keep the instruction manual at hand and follow instruction for use.
-
Page 2: Table Of Contents
CONTENTS Explanation of Text/Symbols on Device Label/Packaging ..................3 Copyright Notice ............5 Safety Notes ..............6 EMC Guidance and Manufacturer's Declaration .... 9 Assembly ..............13 Using Device .............. 18 Product Specifications ..........19 Declaration of Conformity .......... 24... -
Page 3: Explanation Of Text/Symbols On Device Label/Packaging
Explanation of Text/Symbols on Device Label/Packaging Text/Symbol Meaning Caution, consult accompanying documents before use Separate collection for waste of electrical and electronic equipment, in accordance with Directive 2002/96/EC. Do not dispose of device with everyday waste Name and address of device manufacturer, and year/country of manufacture Carefully read user manual before installation and usage, and follow instructions for use. - Page 4 Device complies with EC directives (verified models only) M: Conformity label in compliance with Directive 2014/31/EU for non-automatic weighing instruments 20: Year in which conformity verification was performed and the CE label was applied. (ex: 16=2016) 0122: Identifier for metrology Notified Body Device is a Class III scale in compliance with Directive 2014/31/EU (verified models only) Name and address of entity importing device (if...
-
Page 5: Copyright Notice
This user manual is protected by international copyright law. All content is licensed, and usage is subject to written authorization from Charder Electronic Co., Ltd. (hereinafter Charder) Charder is not liable for any damage caused by a failure to adhere to requirements stated in this manual. Charder reserves the right to correct misprints in the manual without prior notice, and modify the exterior of the device for quality purposes without customer consent. -
Page 6: Safety Notes
Safety Notes A. General Information Thank you for choosing this Charder Medical device. It is designed to be easy and straightforward to operate, but if you encounter any problems not addressed in this manual, please contact your local Charder service partner. Before beginning operation of the device, please read this user manual carefully, and keep it in a safe place for reference. -
Page 7: General Handling
(b) Minimum knowledge: - To be able to read at a high-school level and understand Arabic numerals (e.g. 1, 2, 3, 4...) - Basic hygiene knowledge - Trained in device's operation - Read the instruction manual (c) Language - Able to read the language of instruction manual and screen instructions (d) Qualifications - No special certifications or qualifications required... -
Page 8: Maintenance
Device surface should be cleaned using alcohol-based wipes. Corrosive cleansing liquids should not be used. Maintenance Please contact your local Charder distributor for regular maintenance and calibration, regular checking of accuracy is recommended; frequency to be determined by level of use and state of device. -
Page 9: Emc Guidance And Manufacturer's Declaration
EMC Guidance and Manufacturer's Declaration Guidance and manufacturer’s declaration-electromagnetic emissions The product isintended for use in the electromagnetic environment specified below. The customer or the user of the product should assure that it is used in such an environment. Emission test Compliance Electromagnetic environment-guid... - Page 10 Guidance and manufacturer’s declaration-electromagnetic immunity The product is intended for use in the electromagnetic environment specified below. The customer or the user of the product should assure that it is used in such an environment. Immunity test IEC 60601 Compliance level Electromag test level netic...
- Page 11 hospitalenviro nment. NOTE UT is the a.c. mains voltage prior to application of the testlevel. Guidance and manufacturer’s declaration-electromagnetic immunity Theproduct is intended for use in the electromagnetic environment specified below. The customer or the user of the product should assure that is used in such and environment. Immunity test IEC 60601 test Compliance...
- Page 12 fectedbyabsorptionand reflection from structures, objects andpeople. Field strengths from fixed transmitters, such as base stations for radio (cellular/cordless) telephones and land mobile radios,amateurradio,AMandFMradiobroadcastandTVbroadcastcannotbepredictedtheore ticallywithaccuracy.To assess the electromagnetic environment due to fixed RF transmitters, an electromagnetic site survey should be considered. If the measured field strength in the location in which the product is used exceedstheapplicable RF compliance level above, the product should be observed to verify normal operation.
-
Page 13: Assembly
Assembly Parts Ultrasonic Height Stadiometer Rod A Ultrasonic Height Stadiometer Rod B Parts Included Parts Name Diagram Qty. Phillips round combo screw (for attaching headpiece to metal rod) Round-head screw (longer) (for attaching fixing block to column) Fixing block (for attaching stadiometer to column) Round-head screw (shorter) -
Page 14: Installation
Installation a. Use 4 longer round-head screws [D] to attach fixing blocks [E] to column. - Page 15 b. Use longer round-head screws [D] to attach rod [B] to fixing blocks.
- Page 16 c. Use Phillips round combo screw [C] to attach headpiece to rod [A]. d. Slide rubber gasket [G] into rod [A]. Insert rod [A] into rod [B] and use round-head screws [F] to secure rods together.
- Page 17 Connecting Height Stadiometer Cable Locate 6 pin DIN port on bottom of indicator, and connect transfer cable.
-
Page 18: Using Device
Using Device Stand still and look forward to ensure height measurement accuracy. The device will automatically measure height and transfer result to weighing scale. Indicator will display weight, height and BMI. -
Page 19: Product Specifications
Product Specifications Model HM200U Range 120-200 cm Height Graduati 0.1 cm Measurement Accuracy ± 1.2 cm 500(L) x 61(W) x 2083(H) Overall Dimensions (approximate) Device 1.4kg weight Data Transmission Transfer cable to indicator +5℃~+35℃ Operation Environment 15%~85% RH 700 hPa ~1060 hPa... - Page 20 Notes _______________________________________________ _______________________________________________ _______________________________________________ _______________________________________________ _______________________________________________ _______________________________________________ _______________________________________________ _______________________________________________ _______________________________________________ _______________________________________________ _______________________________________________ _______________________________________________ _______________________________________________ _______________________________________________ _______________________________________________ _______________________________________________ _______________________________________________...
- Page 21 Notes _______________________________________________ _______________________________________________ _______________________________________________ _______________________________________________ _______________________________________________ _______________________________________________ _______________________________________________ _______________________________________________ _______________________________________________ _______________________________________________ _______________________________________________ _______________________________________________ _______________________________________________ _______________________________________________ _______________________________________________ _______________________________________________ _______________________________________________...
- Page 22 Notes _______________________________________________ _______________________________________________ _______________________________________________ _______________________________________________ _______________________________________________ _______________________________________________ _______________________________________________ _______________________________________________ _______________________________________________ _______________________________________________ _______________________________________________ _______________________________________________ _______________________________________________ _______________________________________________ _______________________________________________ _______________________________________________ _______________________________________________...
- Page 23 Notes _______________________________________________ _______________________________________________ _______________________________________________ _______________________________________________ _______________________________________________ _______________________________________________ _______________________________________________ _______________________________________________ _______________________________________________ _______________________________________________ _______________________________________________ _______________________________________________ _______________________________________________ _______________________________________________ _______________________________________________ _______________________________________________ _______________________________________________...
-
Page 24: Declaration Of Conformity
Declaration of Conformity This product has been manufactured in accordance with the harmonized European standards, following the provisions of the below stated directives: (EU) 2017/745 Regulation on Medical Devices 2014/31/EU Non-automatic Weighing Instruments Directive (OIML models only) RoHS Directive 2011/65/EU and Delegated Directive (EU) 2015/863 Radio Equipment Directive 2014/53/EU (applicable if wireless module is used)
