Preface
This service and reference manual contains the technical information necessary to set up,
maintain, troubleshoot, and repair the NEC Versa™ Series MediaDock audio system. It
also provides hardware and interface information for users who need an overview of the
system design. The manual is written for NEC-trained customer engineers, system analysts,
service center personnel, and dealers.
The manual is organized as follows:
Section 1
Technical Information, provides an overview of the hardware and interface
components. System specifications are listed including MediaDock dimensions, environ-
ment, safety compliance, and power consumption.
Section 2
Setup and Operation, takes the user from unpacking to setup and operation.
The section includes a description of operating controls, setting parameters and accessing
the NEC bulletin board system (BBS).
Section 3
Options, provides the user with installation procedures for MediaDock op-
tions.
Section 4
Troubleshooting and Repair, includes maintenance, troubleshooting, disas-
sembly and reassembly, and illustrated parts breakdown information. NEC service and spare
parts ordering information is also provided. Included is a list of NEC service and informa-
tion telephone numbers that provide access to the NEC Bulletin Board System (BBS),
FASTFACTS, and Technical Information Bulletins.
Appendix A
Software Setup for Customized Disks, provides information for using the
MediaDock in conjunction with a hard disk other than the one that shipped with the Versa
system.
Appendix B
System Files, contains CONFIG.SYS and AUTOEXEC.BAT sample files.
The examples reflect the contents of the files after the MediaDock setup utility is run.
An Index is included for convenience.
ix
