Lapierre Overvolt AM 6.6 Assembly Drawing page 7

ÜBERSICHTSZEICHNUNG
ASSEMBLY DRAWING
BOM-ID Description
26 Counter sunk screw
27 Battery Handle
28* Hexagon socket screw (set incl. motor plastic guard) Hex 5 - M6 x 10 mm
28* Motor plastic guard (set incl. screw)
29 Bearing 6902 2RS
30 Hexagon socket screw
31 Hexagon socket screw
32 Spacer
33 Battery Spacer
34 Spacer
35 Spacer
36 Main bolt
37* Key lock (depending which is installed)
Battery Threaded axle (set incl. screw + o-ring)
38*
(depending which is installed)
39* Side cover (set incl. screw)
39* Hexagon socket screw (set incl. side cover)
40 Motor bracket (right side)
41 Motor bracket (left side)
42 Bushing
43* Battery Holder Set
43* Counter sunk screw (included in the set battery holder) Hex 2,5 - M4 x 10 mm
Hexagon nut with flange (included in the set battery
43*
holder)
44 Inox clip
battery holder
Specification
Hex 2,5 - M4 x 16 mm
ø 15 x Ø 28 x 7 mm
Hex 3 - M4 x 6 mm
Hex 5 - M6 x 10 mm
ø 14 x Ø 23 x 40 mm
ø 20 x Ø 32 x 1,1 mm
ø 12 x Ø 20 x 7,5 mm
Hex 6 - ø12 (M12) x 84 mm
Hex 3 - M4 x 10 mm
ø 12 x Ø 18 x 15,5 mm
M4
Torque Drawing no. supplier
3 Nm
WI-38L-115
11 Nm WI-38L-114
WI-38L-114
7287-01004-0012
1.5 Nm 7596-09006-0007
11 Nm 7596-08002-0930
7764-02001-0050
WI-38L-116
7764-02001-0026
7764-01006-0104
18 - 20 Nm 7760-04008-0017
XY2020-DY02-002
G57-A001
WI-38L-122
1.5 Nm WI-38L-122
7134-07009-0946
7134-07009-0947
7764-02001-0051
WI-38L-107
1.5 Nm WI-38L-107
WI-38L-107
7134-04021-0001
Item no. QTY
FRSC0085 2
FROT0082 1
FROT0081 4
FROT0081 1
FROT0128 2
FRSC0079 1
FRSC0080 4
FROT0129 1
FROT0096 1
FROT0130 2
FROT0131 2
FROT0132 1
LO0001 1
FROT0115 1
FROT0116 1
FROT0116 1
FROT0133 1
FROT0134 1
FROT0135 1
FROT0080 1
FROT0080 1
FROT0080 1
SM1719 1
Overvolt AM 6.6 / 7.6 / 8.6 (MY21)
date: 18-12-2020
version: 01
page 7 / 13
