- Page 1 ÜBERSICHTSZEICHNUNG ASSEMBLY DRAWING Overvolt AM 6.6 / 7.6 / 8.6 (MY21) Datum: 18-12-2020 Version: 01 Overvolt AM 6.6 / 7.6 / 8.6 (MY21) date: 18-12-2020 version: 01 page 1 / 13...
- Page 2 - th screw lock for screw threads. red surfaces has to be greased. Overvolt AM 6.6 / 7.6 / 8.6 (MY21) date: 18-12-2020 version: 01 page 2 / 13...
- Page 3 Bosch 1270.016.109 FROT0185 Lockring Bosch 1270.014.085 FROT0180 O-Ring Bosch 1270.016.119 FROT0181 Screw for drive unit M 8 x 16 mm 22 Nm Bosch 1270.016.470 FRSC0097 Overvolt AM 6.6 / 7.6 / 8.6 (MY21) date: 18-12-2020 version: 01 page 3 / 13...
- Page 4 - th screw lock for screw threads. red surfaces has to be greased. Overvolt AM 6.6 / 7.6 / 8.6 (MY21) date: 18-12-2020 version: 01 page 4 / 13...
- Page 5 Hex 5 - M8 x 30 mm 22 Nm 7596-08001-0908 FRSC0078 Bolt for Rocker Hex 6 - ø14 (M10) x 17,5 mm 14 - 18 Nm 7760-04008-0021 FROT0120 Overvolt AM 6.6 / 7.6 / 8.6 (MY21) date: 18-12-2020 version: 01 page 5 / 13...
- Page 6 - th screw lock for screw threads. red surfaces has to be greased. Overvolt AM 6.6 / 7.6 / 8.6 (MY21) date: 18-12-2020 version: 01 page 6 / 13...
- Page 7 Counter sunk screw (included in the set battery holder) Hex 2,5 - M4 x 10 mm 1.5 Nm WI-38L-107 FROT0080 Hexagon nut with flange (included in the set battery WI-38L-107 FROT0080 holder) Inox clip 7134-04021-0001 SM1719 Overvolt AM 6.6 / 7.6 / 8.6 (MY21) date: 18-12-2020 version: 01 page 7 / 13...
- Page 8 - th screw lock for screw threads. red surfaces has to be greased. Overvolt AM 6.6 / 7.6 / 8.6 (MY21) date: 18-12-2020 version: 01 page 8 / 13...
- Page 9 SM0002 Lens head screw TX25 - M 5 x 12 mm 6 Nm Würth SM1190 Clip holder Bosch 1270.016.038 EL0276 Screw Bosch 1270.016.148 EL0277 Overvolt AM 6.6 / 7.6 / 8.6 (MY21) date: 18-12-2020 version: 01 page 9 / 13...
- Page 10 Bearing 6902 2RS ø 15 x Ø 28 x 7 mm 7287-01004-0012 FROT0128 Bearing 6901 2RS ø 12 x Ø 24 x 6 mm 7287-01004-0011 FROT0136 Item no. bearing kit: KE0306 Overvolt AM 6.6 / 7.6 / 8.6 (MY21) date: 18-12-2020 version: 01 page 10 / 13...
- Page 11 22 Nm 7596-08001-0908 FRSC0078 Bolt for Rocker Hex 6 - ø14 (M10) x 17,5 mm 14-18Nm 7760-04008-0021 FROT0120 Item no. rear shock screw kit: KE0304 Overvolt AM 6.6 / 7.6 / 8.6 (MY21) date: 18-12-2020 version: 01 page 11 / 13...
- Page 12 7764-02001-0051 FROT0135 Bolt TX30 - ø 12 x Ø 23 x 21 mm 14-18 Nm 7760-04008-0018 FROT0141 Item no. axle and screw kit: KE0305 Overvolt AM 6.6 / 7.6 / 8.6 (MY21) date: 18-12-2020 version: 01 page 12 / 13...
- Page 13 ----- KICKSTAND: ----- FD TYPE: ----- ISCG STANDARD: ----- ENGINE: BOSCH GEN4 CX CARRIER MOUNT: BATTERY: BOSCH 625 WH FENDER COMPATIBLE: DISPLAY: BOSCH PURION Overvolt AM 6.6 / 7.6 / 8.6 (MY21) date: 18-12-2020 version: 01 page 13 / 13...
- Page 14 Standard Operating Procedure – Battery assembly 15/11/2019 MY20 OV GEN4 AL / HYB ASX Page 1 of 9...
- Page 15 Standard Operating Procedure – Battery assembly 15/11/2019 MY20 OV GEN4 AL / HYB ASX Page 2 of 9 STEP TOOLS PICTURE INSTRUCTIONS Philips screwdriver 1. Clip the Bosch connector on the connector plate 2. Place the 4 springs on the connector plate domes 3.
- Page 16 Standard Operating Procedure – Battery assembly 15/11/2019 MY20 OV GEN4 AL / HYB ASX Page 3 of 9 STEP TOOLS PICTURE INSTRUCTIONS PVC insulating tape 1. On the connector side, tape the power Scissors 40mm cables onto the battery rail (back side) at Power 40mm from the end of the battery rail.
- Page 17 Standard Operating Procedure – Battery assembly 15/11/2019 MY20 OV GEN4 AL / HYB ASX Page 4 of 9 STEP TOOLS PICTURE INSTRUCTIONS HEX wrench 6mm 1. Route the display cable in the DT, on right side HEX wrench 2.5mm Front 2.
- Page 18 Standard Operating Procedure – Battery assembly 15/11/2019 MY20 OV GEN4 AL / HYB ASX Page 5 of 9 STEP TOOLS PICTURE INSTRUCTIONS 1. Route the cables after installing the battery rack (step 3) (When possible. Cable Some bakes have quick hose routing connection...
- Page 19 Standard Operating Procedure – Battery assembly 15/11/2019 MY20 OV GEN4 AL / HYB ASX Page 6 of 9 STEP TOOLS PICTURE INSTRUCTIONS 1. Assemble the drive unit 2. Assemble the motor cover assembly Motor Cover (set incl. screw M6x10): FROT0081 Parts: WI-38L-114 GEN4 Motor Cover...
- Page 20 Standard Operating Procedure – Battery assembly 15/11/2019 MY20 OV GEN4 AL / HYB ASX Page 7 of 9 STEP TOOLS PICTURE INSTRUCTIONS HEX wrench 3mm 1. 500Wh BATTERY: screw the 500Wh Inox clip: HEX wrench 2.5mm battery spacer onto the battery Battery SM1719 2.
- Page 21 Standard Operating Procedure – Battery assembly 15/11/2019 MY20 OV GEN4 AL / HYB ASX Page 8 of 9 STEP TOOLS PICTURE INSTRUCTIONS Brake cleaner 1. Spray some brake cleaner on the rubber (spray) guide rails Rubber 2. Insert the rubber guides into the battery 60mm guides rails...
- Page 22 Standard Operating Procedure – Battery assembly 15/11/2019 MY20 OV GEN4 AL / HYB ASX Page 9 of 9 STEP TOOLS PICTURE INSTRUCTIONS 1. Slowly insert the battery into the DT parallel with the DT axis Battery 2. Slightly lift up the battery to not hook the installation DT edges 3.
