Lapierre Overvolt AM 6.6 Assembly Drawing page 5

ÜBERSICHTSZEICHNUNG
ASSEMBLY DRAWING
BOM-ID Description
19 Bearing 6900 2RS
20 Rocker Link-top
21 Rocker Link
22 Bolt for Rocker
23 Bolt for Rocker
24 Counter sunk screw
25 Bolt for Rocker
rocker
Specification
ø 10 x Ø 22 x 6 mm
Hex 6 - ø14 (M10) x 17,5 mm 14 - 18 Nm 7760-04008-0019
Hex 6 - ø12 (M10) x 17 mm
Hex 5 - M8 x 30 mm
Hex 6 - ø14 (M10) x 17,5 mm 14 - 18 Nm 7760-04008-0021
Torque Drawing no. supplier
7287-01004-0025
7321-11004-0008
7321-03009-0008
14 - 18 Nm 7760-04008-0020
22 Nm 7596-08001-0908
Item no. QTY
FROT0119 8
FROT0123 1
FROT0124 1
FROT0125 2
FROT0126 4
FRSC0078 1
FROT0120 2
Overvolt AM 6.6 / 7.6 / 8.6 (MY21)
date: 18-12-2020
version: 01
page 5 / 13
