Customizing Your System With The Versabay Ii - NEC VERSA 6220 User Manual

Align the CD-ROM reader in the VersaBay II and push it in until it locks
5.
into place.
Turn the system over and open the LCD panel.
6.
7. Power on the system.

Customizing Your System with the VersaBay II

Customizing your NEC Versa is easy using the VersaBay II. If you find you
require additional hard disk space or increased battery longevity, simply
remove the standard device and plug in an optional hard disk drive or
battery.
NOTE
can be set to either master or slave.
However, if you install a hard disk drive from a Versa model E, V,
M, or P in the VersaBay II, it becomes the master drive from which
the system boots.
4-10 Using Your NEC Versa
If you install a second hard disk drive in the VersaBay II, it
Inserting the CD-ROM reader
