MODBUS MAP:
On Modbus side, the map is created automatically. In relation to the configuration defined, it is possible to have two different maps.
Read with Input Register / Status Function not enabled
Data in reading:
Type
Holding Register
Holding Register
Holding Register
Holding Register
Data in writing:
Type
Holding Register
Holding Register
Holding Register
Holding Register
Note:
The data can be read/written as single bits too using Coil Status (Function 01 and Functions 05/15).
ADFweb.com Srl – IT31010 – Mareno – Treviso
Address Function
0
1
2
.
999
Address Function
0
1
2
.
999
User Manual Modbus Slave / SNMP Manager
Document code: MN674-A010_ENG
Description
"Position" 0-1 (data read from SNMP)
03
"Position" 2-3 (data read from SNMP)
03
"Position" 4-5 (data read from SNMP)
03
"Position" 1998-1999 (data read from
03
SNMP)
Description
"Position" 0-1 (data written to SNMP)
06/16
"Position" 2-3 (data written to SNMP)
06/16
"Position" 4-5 (data written to SNMP)
06/16
"Position" 1998-1999 (data written to
06/16
SNMP)
