In the field "Num Bytes" it is possible to select define the dimension of the SNMP Data;
In the field "Conversion" it is possible to select the conversion to apply to the data read/written from/to the SNMP Agent;
In the field "Mnemonic" a description of the data inserted in the row is defined.
Note:
If the field "On change" and "On Timer" is checked and the "Poll Time" is different from 0, the converter sends the SNMP writing
request cyclically and also when the data is changed.
Note:
If the "Trap" mode is used, the fields "On CMD", "On Change" and "On Timer" must be disabled.
