6-18
Minitower Repair
5.
Remove the four screws securing the power supply to the system unit (see
Figure Section 6-3).
6.
Slide the power supply toward the front of the system unit to release the two tabs
at the top of the chassis and remove the power supply from the system unit.
Screws
Figure Section 6-3 Power Supply Screws
Tabs
Power
Supply
