DFI RPS183 User Manual page 9

Specifications
POWER Type
Connector
Consumption
RTC Battery
OS SUPPORT Microsoft
Linux
ENVIRONMENT Temperature
Humidity
MTBF
MECHANISM Dimensions
Height
STANDARDS AND CERTIFICATIONS Certifications
User's Manual | RPS183
RPS183-Q670E
DC IN
4-pin Terminal 19~24V DC-In
Idle: i9-13900E 65W with MXM A4500:
24V @ 2.03A (48.72W), 19V @ 2.50A (47.50W)
Max: i9-13900E 65W with MXM A4500: 24V @ 11.66A (279.84W),
19V @ 14.73A (279.87W)
Idle: i9-13900E 65W :
24V @ 2.60A (62.40W), 19V @ 3.13A (59.47W)
Max: i9-13900E 65W:
24V @ 6.40A (153.60W), 19V @ 8.08A (153.52W)
CR2032 Coin Cell
Windows IoT Enterprise 10 LTSB, Windows 11 IoT Enterprise(64-bit)_23H2
Linux Ubuntu 22.04
Operating w/o MXM: -5°C ~ 65°C
Operating w/i MXM: By MXM spec
Storage: -40°C ~ 85°C
Operating: 5 to 90% RH
Storage: 5 to 90% RH
RPS183-Q670E 480,169 hrs @ 25°C; 281,641 hrs @ 45°C; 182,084
hrs @ 60°C;
Calculation model: Telcordia Issue 4
Environment: GB, GC – Ground Benign, Controlled
Mini-ITX Form Factor: 195mm (7.7") x 170mm (6.7")
PCB: 1.6mm
Top Side: 26.0mm (Audio); 25.79mm (RJ45)
Bottom Side: 13.53m
CE, FCC, RoHS
RPS183-H610E
Idle: i9-13900E 65W with MXM A4500:
24V @ 2.03A (48.72W), 19V @ 2.50A (47.50W)
Max: i9-13900E 65W with MXM A4500: 24V @ 11.66A (279.84W),
19V @ 14.73A (279.87W)
Idle: i9-13900E 65W :
24V @ 2.60A (62.40W), 19V @ 3.13A (59.47W)
Max: i9-13900E 65W:
24V @ 6.40A (153.60W), 19V @ 8.08A (153.52W)
RPS183-H610E 480,169 hrs @ 25°C;
281,641 hrs @ 45°C; 182,084 hrs @ 60°C;
Calculation model: Telcordia Issue 4
Environment: GB, GC – Ground Benign, Controlled
Chapter 1
INTRODUCTION
9
