Specifications RPS183-Q670E
SYSTEM Processor 12th Generation Intel® LGA 1700 Socket Processors, TDP support up to 65W
Intel
Intel
Intel
Intel
Intel
Intel
Intel
Intel
Intel
Intel
Intel
Intel
Chipset Intel
Memory 2x 262-pin SODIMM up to 64GB
Dual Channel DDR5 4800MHz
BIOS AMI SPI 256Mbit
GRAPHICS Controller Intel
Feature OpenGL 4.5, DirectX 12, OpenCL 2.1
HW Decode: AVC/H.264, MPEG2, VC1/WMV9, JPEG/MJPEG, HEVC/H265, VP8, VP9
HW Encode: MPEG2, AVC/H264, JPEG, HEVC/H265, VP8, VP9
Display 1 x DP++(CPU): Resolution up to 4096x2304 @ 60Hz
1 x DP++(MXM): Resolution by MXM
1 x USB Type C: DP Alt-mode, Resolution up to 4096x2304 @60Hz
1 x eDP(MXM): Resolution by MXM
1 x Internal HDMI: Resolution by MXM
Multiple Displays 1 DP++ (CPU) + 1 DP++ (MXM) + 1 USB Type C (DP Alt-mode) + 1 eDP (MXM) + 1 internal HDMI (MXM)
User's Manual | RPS183
Core™ i9-12900E (16 Cores, 30M Cache, up to 5.0 GHz); 65W
®
Core™ i9-12900TE (16 Cores, 30M Cache, up to 4.8 GHz); 35W
®
Core™ i7-12700E (12 Cores, 25M Cache, up to 4.8 GHz); 65W
®
Core™ i7-12700TE (12 Cores, 25M Cache, up to 4.6 GHz); 35W
®
Core™ i5-12500E (6 Cores, 18M Cache, up to 4.5 GHz); 65W
®
Core™ i5-12500TE (6 Cores, 18M Cache, up to 4.3 GHz); 35W
®
Core™ i3-12100E (4 Cores, 12M Cache, up to 4.2 GHz); 60W
®
Core™ i3-12100TE (4 Cores, 12M Cache, up to 4.0 GHz); 35W
®
Pentium G7400E (2 Cores, 6M Cache, 3.6 GHz); 46W
® ®
Pentium G7400TE (2 Cores, 6M Cache, 3.0 GHz); 35W
® ®
Celeron G6900E (2 Cores, 4M Cache, 3.0 GHz); 46W
® ®
Celeron G6900TE (2 Cores, 4M Cache, 2.4 GHz); 35W
® ®
Q670E Chipset
®
UHD Graphics 700 series
®
RPS183-H610E
Intel H610E Chipset
®
