DFI RPS183 User Manual page 8

Specifications
EXPANSION Interface
AUDIO Audio Codec
ETHERNET Controller
REAR I/O Ethernet
USB
Display
Audio
INTERNAL I/O USB
Display
Serial
SATA
DIO
SPI
I2C
FAN
WATCHDOG TIMER Output & Interval
SECURITY TPM
User's Manual | RPS183
RPS183-Q670E
1 x PCIe Gen 3 x4 (Locate at board side)
1 x M.2 2280 M Key (PCIE Gen3x4, SATA3)
1 x M.2 2230 E Key (PCIE Gen3x, USB 2.0, support Intel® CNVi) 1 x MXM Type-A/B/B+
1x M.2 2242/3042/3052 B Key (PCIE Gen3x1, USB 3.2 Gen2, USB 2.0)
Realtek ALC888S
1 x Intel I226LM(vPro) (10/100/1000/2500Mbps)
®
1 x Intel I226V (10/100/1000/2500Mbps)
®
2 x 2.5GbE (RJ-45)
4 x USB 3.2 Gen2 or
3 x USB 3.2 Gen2+ 1 x USB Type C
1 x DP++, 1 DP++(MXM)
1 x USB Type C
1 Audio Jack (Line-out/Mic-in)
1 x USB 2.0 Type A
1 x eDP(MXM)
1 x HDMI(MXM)
2 x RS-232/422/485
1 x SATA 3.0
1 x 8-bit DIO (BOX HEADER 1*10P/1.00mm)
1 x SPI (BOX HEADER 1*7P/1.25mm)(For OOB)
2 x I2C (BOX HEADER, 1*5P/1.0m)
1 x CPU, 2 x System (WAFER,1*4P/1.25mm)
System Reset, Programmable via Software from 1 to 255 Seconds
dTPM (default)
fTPM (option)
INTRODUCTION
RPS183-H610E
1x M.2 2242/3042/3052 B Key (PCIE Gen3x1, USB 3.2 Gen1, USB 2.0)
1 x Intel I219V (10/100/1000/2500Mbps)
®
1 x Intel I226V (10/100/1000/2500Mbps)
®
2 x USB 3.2 Gen2 + 2 x USB 2.0 or
2 x USB 3.2 Gen2 + 1 x USB Type C
