Warning notices: Before using this product, please read this manual carefully and keep it for future reference.
The design and specifications are subject to change without prior notice for product improvement.
Consult with your dealer or manufacturer for details.
The diagram above is just for reference. Please take the appearance of the actual product as the standard.
Cooker Hood
USER MANUAL
MH60M21ET33SG-UK
MH90M21ET33SG-UK

Advertisement

Table of Contents
loading
Need help?

Need help?

Do you have a question about the MH60M21ET33SG-UK and is the answer not in the manual?

Questions and answers

Summary of Contents for Midea MH60M21ET33SG-UK

  • Page 1 Cooker Hood USER MANUAL MH60M21ET33SG-UK MH90M21ET33SG-UK Warning notices: Before using this product, please read this manual carefully and keep it for future reference. The design and specifications are subject to change without prior notice for product improvement. Consult with your dealer or manufacturer for details.
  • Page 2: Table Of Contents

    THANK YOU LETTER Thank you for choosing Midea! Before using your new Midea product, please read this manual thoroughly to ensure that you know how to operate the features and CONTENTS THANK YOU LETTER SAFETY INSTRUCTIONS SPECIFICATIONS PRODUCT OVERVIEW PRODUCT INSTALLATION...
  • Page 3: Safety Instructions

    SAFETY INSTRUCTIONS Intended Use The following safety guidelines are intended to prevent unforeseen risks or damage from unsafe or incorrect operation of the appliance. Please check the packaging and appliance on arrival to make sure everything is intact to ensure safe operation. If you find any damage, please contact the retailer or dealer.
  • Page 4 WARNING The instructions for Use apply to several versions of this appliance. Accordingly, ● you may find descriptions of individual features that do not apply to your specific appliance. This appliance is not intended for use by persons (including children) with reduced ●...
  • Page 5: Specifications

    Switch off or unplug the appliance from the mains supply before carrying out any ● maintenance work. Clean the hood using a damp cloth and a neutral liquid detergent. ● SPECIFICATIONS Product Model MH60M21ET33SG-UK/MH90M21ET33SG-UK Voltage 220V-240V~/60Hz Rated Power 82 W Lighting Power 1 W x 2...
  • Page 6: Product Overview

    PRODUCT OVERVIEW Components Ref. Qty. Product Components Hood Body,complete with: Controls, Light, Blower,Filter. Lower Decorative Chimney Upper Decorative Chimney Flange ( optional ) Exhaust Pipe ( optional ) The Activated Charcoal filter ( optional ) Qty. Documentation Instruction Manual Ref. Qty.
  • Page 7 Dimensions unit:mm Min. Min. 650mm 650mm Option Chimney Height 400+390 430 465-800 430-800 500+490 565-1000 530-1000 600+590 665-1200 630-1200...
  • Page 8: Product Installation

    PRODUCT INSTALLATION Wall Drilling And Bracket Fixing 100 100 Option Chimney 400+390 160-500 500+490 260-700 600+590 360-900 As a first step, proceed with the following drawings: l line up to the ceiling or up to the upper limit, at the center of the area in which the ●...
  • Page 9 Lower Decorative Chimney Fix the exhaust pipe on the hood body, ● connect chimney and hood body with 2 screws 12. connect chimney fixing bracket and chimney with 2 screws 12. 4 Screws(ST4.2*9.5) Hook The Hood Body Hook the hood body to the bracket 20. ●...
  • Page 10: Operation Instructions

    OPERATION INSTRUCTIONS Speed Adjustment. (For Some Models) Button Function Remarks Turns the lighting system on or off. Button on. Decrease the motor speed. When are on. When the fan is running. Display fan gear “1、2、3、b”. Delayed shutdown mode, Display "0". or standby mode.
  • Page 11: Cleaning And Maintenance

    CLEANING AND MAINTENANCE Grease Filters CLEANING METAL SELF-SUPPORTING GREASE FILTERS The filters must be cleaned every 2 months of operation, or ● more frequently for particularly heavy usage, and can be washed in a dishwasher. Remove the filters one by one pushing them towards the back ●...
  • Page 12 Lighting LIGHT REPLACEMENT(Completed by professionals) Replacing the light modules Cannot replaced the light bulbs, the entire light module has to be replaced. ● When changing the light modules, the contacts are live. ● Before changing the light module(s), unplug the appliance from the mains or switch off ●...
  • Page 13: Troubleshooting

    TROUBLESHOOTING Problem Possible reason Solution The blades are blocked. Check the blades ● The capacitor is damaged. Replace capacitor. ● Light on, but motor The motor is damaged. Replace motor. ● does not work The internal wiring of motor Replace motor. ●...
  • Page 14: Trademarks, Copyrights And Legal Statement

    Midea may constitute trademark infringement or unfair competition in violation of relevant laws. This manual is created by Midea and Midea reserves all copyrights thereof. No entity or individual may use, duplicate, modify, distribute in whole or in part this manual, or bundle or sell with other products without the prior written consent of Midea.
  • Page 15: Data Protection Notice

    European Economic Area. Further information are provided on request. You can contact our Data Protection MideaDPO@midea.com. To exercise your rights such as right to object your personal date being processed for direct marketing purposes, please contact us via MideaDPO@midea.com. To find further information, please follow the QR Code.
