- Page 1 Midea Cooker Hood Instruction MODEL : MHC60SS MHC90SS SAVE THESE INSTRUCTIONS CAREFULLY Read these instructions carefully before using your cooker hood,and keep it carefully. If you follow the instructions, your cooker hood will provide you with many years of good service.
-
Page 2: Recommendations And Suggestions
RECOMMENDATIONS AND SUGGESTIONS The instructions for Use apply to several versions of this appliance. Accordingly, you may find descriptions of individual features that do not apply to your specific appliance. INSTALLATION The manufacturer will not be held liable for any damages resulting from incorrect or improper installation. - Page 3 COMPONENTS Ref. Qty. Product Components Hood Body,complete with: Controls, Light, Blower,Filter. Lower Decorative Chimney Upper Decorative Chimney( optional ) Flange ( optional ) Exhaust Pipe The Activated Charcoal filter ( optional ) Qty. Documentation Instruction Manual Ref. Qty. Standard Installation Components Screws 5 x 50 Wall Plugs Screws 4,2 x 9,5...
- Page 4 unit：mm Min. Min. 650mm 650mm Option Chimney 400+0 400+300 689 730-970 400+390 689 730-1060...
-
Page 5: Installation
INSTALLATION WALL DRILLING AND BRACKET FIXING C(solution2) Option Chimney 400+0 400+300 390-620 400+390 390-710 As a first step, proceed with the following drawings: l line up to the ceiling or up to the upper limit, at the center of the area in which the hood is ... - Page 6 Hook the hood body Hook the hood body to the bracket 20. Level the hood body itself. Lock screws (M5*12) on the hood fixing bracket to prevent the hood body from accidently sliding off . Remove the filter,from the inside of the hood body, fix the screws 10 to Wall Plugs 11 at the points (3)(solution2).
- Page 7 CHIMNEY ASSEMBLY The chimney can only be installed with exhausting hood. Lower Decorative Chimney Fix the Lower Decorative Chimney to the hood body with 2 screws 12 (4.2 x 9.5) supplied with the hood. 2×Screws （ST4.2*9.5） Upper Decorative Chimney ...
- Page 8 Speed adjustment. OFF MOTOR SWITCH: Press on this switch to stop the motor operation. SPEED SWITCH: Press on this switch, the motor runs at LOW speed. SPEED SWITCH: Press on this switch, the motor runs at MEDIUM speed. SPEED SWITCH: Press on this switch, the motor runs at HIGH speed.
-
Page 9: Maintenance
MAINTENANCE GREASE FILTERS CLEANING METAL SELF-SUPPORTING GREASE FILTERS The filters must be cleaned every 2 months of operation, or more frequently for particularly heavy usage, and can be washed in a dishwasher. Remove the filters one by one pushing them towards the back ... - Page 10 Remove the grease filter and carefully remove the 2 screws from the front plate (a cross headed screwdriver will be needed to remove the screws). Disconnect the terminal of LED light. Press LED light on the back of the front plate, take the LED light out. ...
-
Page 11: Troubleshooting
TROUBLE SHOOTING Fault Cause Solution The blades are blocked. Check the blades. The capacitor is damaged. Replace capacitor. Light on, but The motor is damaged. Replace motor. motor does not The internal wiring of motor is cut off/ work Replace motor. disconnected. - Page 12 P/N:16173000A09198...
