Summary of Contents for Midea MHAT90S
- Page 1 Midea Cooker Hood Instruction MODEL：MHAT90S SAVE THESE INSTRUCTIONS CAREFULLY Read these instructions carefully before using your cooker hood,and keep it carefully. If you follow the instructions, your cooker hood will provide you with many years of good service.
-
Page 3: Table Of Contents
Contents Important information Safety warning Product structure schematic The attachment list Outline dimensions Control panel and function comments Precautions Daily maintenance Product parameters The installation guide Installation instructions Electrical schematic diagram Clean and maintain... -
Page 4: Important Information
Important information ● All packaging materials are environment-friendly and recyclable. Please dispose these packaging materials in an environmentally friendly manner so as to maintain a good environment. ● Please do not allow children to play with plastic film and packing boxes, which may cause asphyxiation. -
Page 5: Product Structure Schematic
Product structure schematic Adjustable Decorative cover Decorative cover Switch panel Guide plate Cold plate Water inlet lighting Oil cup The attachment list Ref. Qty. Product Components Ref. Qty. Product Components Exhaust pipe Water cup Exhaust pipe fixed ring Filter cotton Check valve Screws(ST4.2×16) Decorative cover plate... -
Page 6: Outline Dimensions
Outline dimensions See page 8 specification for long and wide dimensions 403mm 313mm 0~310mm high wide long Control panel and function comments It can be used after power supply Short press:0.5 second Long press:2~3 seconds Light Short press:Turn on the light ; Long press:Adjust the light. Time Short press time: Hour key flashing, Short press speed: adjust hour;... -
Page 7: Precautions
gear display ( gear ) time delay display display 3-2-1（minute） Steam washing clean air dry（minute） clock display （clock） When the indicator light is on for 3 hours, the indicator light will be lit. After the indicator light is lit, the steam washing icon will flash 10 times next time, reminding the user to clean the cigarette machine. -
Page 8: Daily Maintenance
Daily maintenance Steam washing (machine internal cleaning) Indicator light flashing Water cup is filled remove oil cup The instructions require with pure water to Pour out the product oil steam washing. live distilled water. Put back into the oil cup Insert the water cup Long press the steam washing aqueduct into the inlet. - Page 9 Internal clean Cleaning impeller and volute should be completed by professionals. First, unplug the power plug, remove Remove the decorative cover the machine and place it in a reliable position, remove the decorative cover and set screw. screw Remove the screws on the frame Remove the screw from the volute and cover and remove the frame cover.
-
Page 10: Product Parameters
Guide for disassembly of condensates and filters Remove the condenser plate to indicate 1. Hold the condenser with both hands, 2. After the condenser is opened, hold and press the left and right sides to the condenser with both hands and open the condenser. -
Page 11: The Installation Guide
Dismantle LED linght module ● Noise: for the sound power level of A, the average sound pressure level noise is 55dB (A). ● Wind volume, maximum static pressure: the measured value and the express value should not exceed the value of -10%. ●... -
Page 12: Install The Machine
Install check valve Install the check valve components together with the check The check valve valve seal pad in the position of the rack outlet, tighten with Check valve gasket 4 ST4.2 x 16 screws at random, check and make sure that the disc is rotating flexibly. -
Page 13: Installation Instructions
Install check valve Hold the bottom end of the oil cup with both hands Oil cup stents and place the oil cup horizontally. Insert the oil cup into the holder of the oil cup holder and push the oil cup back to the county seat. Pins Oil cup Install cold plate... -
Page 14: Electrical Schematic Diagram
Electrical schematic diagram 220V-240V~/50Hz (Blue) (Red) (Orange) (Brown) (Black) Temperature Sensor Steam generator (White) (Yellow) Heat protector (Red) Tump (Black) Heat protector Light Clean and maintain Before cleaning, please note that when you need to clean the condenser and screen, cut off the power and unplug the power. - Page 16 P/N:16173000A10872...
