Cooker Hood
USER MANUAL
60L03-EM23-00301
Warning notices: Before using this product, please read this manual carefully and keep it for future reference.
The design and specifications are subject to change without prior notice for product improvement.
Consult with your dealer or manufacturer for details.
The diagram above is just for reference. Please take the appearance of the actual product as the standard.

Advertisement

Table of Contents
loading
Need help?

Need help?

Do you have a question about the 60L03-EM23-00301 and is the answer not in the manual?

Questions and answers

Summary of Contents for Midea 60L03-EM23-00301

  • Page 1 Cooker Hood USER MANUAL 60L03-EM23-00301 Warning notices: Before using this product, please read this manual carefully and keep it for future reference. The design and specifications are subject to change without prior notice for product improvement. Consult with your dealer or manufacturer for details.
  • Page 2: Table Of Contents

    THANK YOU LETTER Thank you for choosing Midea! Before using your new Midea product, please read this manual thoroughly to ensure that you know how to operate the features and functions that your new appliance o ers in a safe way.
  • Page 3: Safety Instructions

    SAFETY INSTRUCTIONS Intended Use The following safety guidelines are intended to prevent unforeseen risks or damage from unsafe or incorrect operation of the appliance. Please check the packaging and appliance on arrival to make sure everything is intact to ensure safe operation. If you find any damage, please contact the retailer or dealer.
  • Page 4 WARNING The instructions for Use apply to several versions of this appliance. Accordingly, you ● may find descriptions of individual features that do not apply to your specific appliance. This appliance is not intended for use by persons (including children) with reduced ●...
  • Page 5 This appliance is for indoor household use only. ● To protect against the risk of electrical shock, do not immerse the unit, cord or plug in ● water or other liquid. Please unplug before cleaning and maintenance the appliance . ●...
  • Page 6: Specifications

    SPECIFICATIONS Product Model 60L03-EM23-00301 Voltage 220-240V~/50Hz Rated Power 126.5 W Lighting Power 1.5 W Motor Power 125W Diameter of air tube 120 mm Air flow 180m Noise ≤65 dB(A)
  • Page 7: Product Overview

    PRODUCT OVERVIEW Components Ref. Qty. Product Components Hood Body,complete with: Controls, Light, Blower,Filter. Check valve Screws 5 x 50 Wall Plugs...
  • Page 8 Dimensions unit:mm Min. Min. OPTIONAL 43/80 650mm 650mm OPTIONAL 28/25/18...
  • Page 9: Product Installation

    PRODUCT INSTALLATION Method 1 OPTIONAL 28/25/18 According to the figure, make sure the position of hood in the cabinet. The wood ● strips should be line up with the 4 keyholes slots on the top of the range hood. On the cabinet, install 4 screws (supplied) according to the relative position of 4 key holes on the bottom of hood.
  • Page 10 Method 2 In the installation surface in cabinet don’t adapt to install the cooker hood, then as ● per fig, fix the position of cooker hood on the wall. On the wall, install 2 screws ( supplied ) according to the relative position of 2 key ●...
  • Page 11 Choose A Venting Mode Here two venting modes, extraction-air mode and recirculation mode, before installing should be select one of them. Extraction-air mode, the air is discharged out of the house by a pipe. Recirculation mode, the air is purified and discharged into the house. Extraction-air mode Recirculation mode Information...
  • Page 12: Operation Instructions

    OPERATION INSTRUCTIONS Speed Adjustment. (For Some Models) Operation Check beforehand Check the safe condition of the appliance: Check whether there are visible defects. ● Check that all parts of the appliance have been securely fitted. ● In the right part of the cooker hood. (For some models) ●...
  • Page 13: Cleaning And Maintenance

    CLEANING AND MAINTENANCE Maintenance CHECK VALVE INSTALLATION Hold on check valve with your hands, align the box ● gap, put in thecheck valve , and then spinto a certain angle until three anglesof the valve are stuck. Installa- tion is complete. Grease Filters CLEANING METAL SELF-SUPPORTING GREASE FILTERS The filters must be cleaned every 2 months of operation, or...
  • Page 14 ACTIVATED CHARCOAL FILTER (RECIRCULATION VERSION) REPLACING THE ACTIVATED CHARCOAL FILTER These filters are not washable and cannot be regenerated, and must be replaced approximately every 4 months of operation, or more frequently with heavy usage. Remove the metal grease filters. ●...
  • Page 15: Troubleshooting

    TROUBLESHOOTING Problem Possible reason Solution The blades are blocked. Check the blades ● The capacitor is damaged. Replace capacitor. ● Light on, but motor The motor is damaged. Replace motor. ● does not work The internal wiring of motor Replace motor. ●...
  • Page 16: Trademarks, Copyrights And Legal Statement

    Midea may constitute trademark infringement or unfair competition in violation of relevant laws. This manual is created by Midea and Midea reserves all copyrights thereof. No entity or individual may use, duplicate, modify, distribute in whole or in part this manual, or bundle or sell with other products without the prior written consent of Midea.
  • Page 17: Disposal And Recycling

    DISPOSAL AND RECYCLING Important instructions for environment Compliance with the WEEE Directive and Disposing of the Waster Product: This product complies with EU WEEE Directive (2012/19/EU). This product bears a classification symbol for waster electrical and electronic equipment (WEEE). This symbol indicates that this product shall not be disposed with other household wastes at the end of its service life.
  • Page 18: Data Protection Notice

    European Economic Area. Further information are provided on request. You can contact our Data Protection MideaDPO@midea.com. To exercise your rights such as right to object your O cer via personal date being processed for direct marketing purposes, please contact us via...
