PANEL DESCRIPTION 4
$ SQUELCH CONTROL [S01]
Varies ine squeich thresnold point for audio mute.
9 VOLUME CONTROL [VOL]
Turns power ON and adjusts the audio level,
While pushing this switch, otner switcnes function as
secondary functions.
PTT SWITCH [PTT]‫‏‬ ‫و‬
Push and hold to transmit; release io receive.‫‏‬
49 BATTERY PACK RELEASE BUTTON
Opens the latch for bottom cap removal when pusned
upwards. (p. 4)
D TRANSMIT POWER SWITCH [HL DTMF]
Seiecis high or low transmit output power. (p. 17)
- While pushing this switch and rotating the tuning
control, the low output power leve! changes. (p, 18)
- M nile pushing [FUNC], push the switch to enter DTMF
EMORY mode. (p. 26)
a WON]
eich and optional ion
Dens i ir 2
o
squeich. (p. 17)
i necks ine transmit frequency when ‫تبع‬‎ is operated
p. 18) or when crossband full duplex 9
While pushing [FUNC], push this switch to turn OFF the
green receive indicator. This function conserves battery
pack power. (p. 17)
LIGHT SWITCH [LIGHT]
Lights the display backlight for approx. 5 se
While pushing [FUNC], push this switch for continuous
lignting. To turn OFF, push this switch again. The
continuous lighting mode remains activated even if the
power switch is turned OFF.
While pushing this switch together with some digit keys,
turn power ON to initialize the scan resume condition
(p. 29), power saver dutv cycle (p. 33) or PTT switch func-
tion. (p. 18)
® MONITOR S
