5-3 1 10
3 ‫د‬ -
CAUTION: Transmittin jg without an antenna may
damage the transceiver.
NOTE: Top
j
'ent interference, listen on ine irequency |
| before Gene using [MONI]. |
~ A 3 zen f. 320 j 5
operating frequency using the tuning control or
o Refer io D. 15 for details.
2) Push [H/U DTMF] to select tne cutout power
a "LOY"? appears Se selecting low power and dis-
appears when selecting high power.
a Low output power level can be changed. fp. 18)
n and held [PTT] io transmit.
ne transmit/receive indicator lignis up in red.
ne S/RF indicator snows output power selection.
4) Speak into the micropnone.
ə DO NOT noid the transceiver too closely io your mouin
or speak too loudly. This may distort the signal.
5) Release [PIT] to receive.
5 BASIC OPERATION
5-2 Receiving
1) Set [SQL] to maximum counterclockwise.
2) Rotate [VOL] to turn ON power and adjust the audio level.
3) Rotate [SQL] clockwise until the noise disappears.
4) Set the operating frequency using the tuning conirol or
keyboard.
e Refer to .‫م‬‎ 15 for details.
5) When receiving a signal on the set frequency: .
- Squelch opens and the transceiver emits audio.
- The S/RF indicator shows relative signal strength.
6) Push [MONI] when a weak signal cannot open the squelch
completely.
B RECEIVE INDICATOR ON/OFF
The receive indicator lights when the squelch opens.
However, it can be turned OFF to conserve battery
pack power.
* While pushing [FUNC], push [MONI] to turn the indicator
OFF or ON.
