9124730
SERVICE MANUAL
MODULAR CONVENIENCE COUNTER
MCC COLD USA
- NOTICE -
This service manual is prepared to be used by trained Service Technicians and should not be used by those not
properly qualified. If you have attended a training for this product, you may be qualified to
Perform all repair procedures, replacements and adjustments described in this service manual.
The information presented in this document is only valid for standard hot and cold modular convenience counters,
(MCC) configurations and is not intended to be all encompassing. The individual specifications may differ.
Procedures for which you do not have the necessary tools, instruments or skills should not be performed by you.
.
Technical data and specifications mentioned in this manual are subject to amendment without prior notice
Reproduction of this service manual,
Without the express written consent of Fri-Jado,
Is prohibited.
