Included Items - Old School Model Works Raider Construction Manual

WARNING
READ THROUGH THIS MANUAL
BEFORE STARTING CONSTRUCTION.
IT CONTAINS IMPORTANT WARNINGS
AND INSTRUCTIONS CONCERNING
THE CONSTRUCTION AND USE OF THIS
MODEL.
A Radio-Controlled aircraft is not a toy!
If misused, it can cause serious bodily harm
and damage to property. Fly only in open
areas, preferably at AMA (Academy of Model
Aeronautics) approved fl ying sites, following all
instructions included with your radio, powerplant,
electronics and batteries.

INCLUDED ITEMS

Wood parts included in this kit:
• 2 LP1 - laser cut 1/8" x 5" x 24" lite ply
• 2 LP2 - laser cut 1/8" x 5" x 24" lite ply
• 2 LP3 - laser cut 1/8" x 2" x 24" lite ply
• 1 LP4 - laser cut 1/8" x 5" x 24" lite ply
• 1 LP5 - laser cut 1/8" x 5" x 24" ply
• 1 LP6 - laser cut 1/8" x 3" x 24" ply
• 1 LP7 - laser cut 1/16" x 3" x 6" ply
• 1 D1 - laser cut dihedral brace - 1/4" ply
• 1 F1 - laser cut fi rewall - 1/4" ply
• 2 BP1 - laser cut 1/8" x 4" x 24" balsa
• 2 BP2 - laser cut 1/8" x 4" x 24" balsa
• 1 BP3 - laser cut 1/8" x 4" x 24" balsa
• 1 BP4 - laser cut 1/8" x 4" x 24" balsa
• 1 BP5 - laser cut 1/8" x 4" x 24" balsa
• 1 BP6 - laser cut 1/8" x 4" x 24" balsa
• 1 BP7 - laser cut 1/8" x 4" x 24" balsa
• 1 BP8 - laser cut 1/8" x 4" x 24" balsa
• 1 BP9 - laser cut 1/8" x 4" x 12" balsa
• 1 BP10 - laser cut 1/8" x 4" x 12" balsa
• 1 BP11 - laser cut 1/8" x 4" x 24" balsa
• 1 BP12 - laser cut 1/8" x 4" x 12" balsa
• 1 BP13 - laser cut 1/8" x 4" x 24" balsa
• 2 BP14 - laser cut 1/16" x 4" x 12" balsa
• 2 BP15 - laser cut 3/32" x 4" x 12" balsa
• 2 BP16 - laser cut 3/32" x 4" x 12" balsa
• 4 BP17 - laser cut 1/16" x 4" x 12" balsa
• 2 BP18 - laser cut 1/16" x 4" x 12" balsa
• 2 BP19 - laser cut 1/16" x 4" x 12" balsa
• 1 BP20 - laser cut 1/16" x 4" x 24" balsa
• 1 BP21 - laser cut 1/16" x 4" x 24" balsa
• 2 BP22 - laser cut 1/16" x 4" x 12" balsa
• 2 BP23 - laser cut 1/16" x 4" x 12" balsa
• 2 BP24 - laser cut 1/16" x 4" x 12" balsa
Page 2
• Inspect your model before every fl ight to ensure it is airworthy.
• Be aware of any other radio frequency user who may present an
interference problem.
• Always be courteous and respectful of other users in your
selected fl ight area.
• Choose an area clear of obstacles and large enough to safely
accommodate your fl ying activity.
• Make sure this area is clear of friends and spectators prior to
launching your aircraft.
• Be aware of other activities in the vicinity of your fl ight path that
could cause potential confl ict.
• Carefully plan your fl ight path prior to launch.
• Abide by any and all established AMA National Model Aircraft
Safety Codes.
IMPORTANT!!!
do to preserve the radio controlled aircraft hobby are to avoid fl ying
near full-scale aircraft and avoid fl ying near or over groups of people.
WARNING: This product can expose you to chemicals including lead, which
is known to the State of California to cause cancer and birth defects or other
reproductive harm. For more information go to www.P65Warnings.ca.gov.
• 2 BP25 - laser cut 1/16" x 4" x 12" balsa
• 2 BP26 - laser cut 1/16" x 4" x 12" balsa
• 1 BP27 - laser cut 1/4" x 4" x 24" balsa
• 4 1/4" x 1/4" x 36" basswood strips
• 1 3/16" x 3/8" x 36" basswood strip
• 2 1/16" x 4" x 36" balsa sheets
• 2 1/16" x 4" x 12" balsa sheets
• 3 1/8" x 4" x 24" balsa sheets
• 4 1/4" x 1/4" x 36" balsa strips
• 4 3/16" x 3/16" x 36" balsa strips
• 2 5/16" x 5/16" x 36" balsa strips
• 2 1/2" x 1/2" x 36" balsa strips
• 2 1/4" x 36" dowels
Hardware parts included in this kit:
• 4 4-40 x 1" socket head cap screws
• 3 4-40 x 1/2" socket head cap screw
• 5 #4 washers
• 5 4-40 t-nuts
• 16 2-56 x 1/2" self tapping screws
• 12 2-56 x 3/4 machine screws
• 2 5/32 axle shafts w/lock nuts
• 2 5/32" wheel collars
• 2 wheel collars set screws
• 6 large control horn
• 2 1/4-20 x 2" wing bolts
• 19 CA hinges
• 1 pre-bent main gear
• 1 nose gear assembly
Other items included in this kit:
• 3 - Rolled plans (fuselage and 2 wing)
• 1 - Construction Manual
• 1 - OSMW sticker sheet
www.oldschoolmodels.com
Two of the most important things you can
Construction Manual
