Included Items; Items Needed - Old School Model Works Mambo Construction Manual

WARNING
READ THROUGH THIS MANUAL
BEFORE STARTING CONSTRUCTION.
IT CONTAINS IMPORTANT WARNINGS
AND INSTRUCTIONS CONCERNING
THE CONSTRUCTION AND USE OF THIS
MODEL.
A Radio-Controlled aircraft is not a toy!
If misused, it can cause serious bodily harm
and damage to property. Fly only in open
areas, preferably at AMA (Academy of Model
Aeronautics) approved flying sites, following all
instructions included with your radio, powerplant,
electronics and batteries.

INCLUDED ITEMS

Wood parts included in this kit:
• 1 - LP1 - laser cut 1/8" x 5.5 x 24 sheet
• 1 - LP2 - laser cut 1/8" x 5.5 x 24 sheet
• 1 - LP3 - laser cut 1/8" x 5.5 x 24 sheet
• 1 - LP4 - laser cut 1/8" x 5.5 x 24 sheet
• 1 - LP5 - laser cut 1/8" x 3.5 x 6 sheet
• 2 - BP1 - laser cut 3/32" x 4 x 24 sheet
• 1 - BP2 - laser cut 3/32" x 4 x 11.5 sheet
• 1 - BP3 - laser cut 3/32" x 4 x 11.5 sheet
• 1 - BP4 - laser cut 3/32" x 4 x 24 sheet
• 1 - BP5 - laser cut 3/32" x 4 x 24 sheet
• 2 - BP6 - laser cut 3/32" x 4 x 24 sheet
• 2 - BP7 - laser cut 3/32" x 4 x 24 sheet
• 1 - BP8 - laser cut 3/32" x 4 x 11.5 sheet
• 1 - BP9 - laser cut 3/32" x 4 x 11.5 sheet
• 2 - BP10 - laser cut 3/32" x 4 x 24 sheet
• 1 - BP11 - laser cut 1/16" x 4 x 24 sheet
• 1 - BP12 - laser cut 1/16" x 4 x 24 sheet
• 1 - BPTIP - laser cut 1/4" x 4 x 9 sheet
• 1 - 3/32" x 12 x 24 sheet
• 3 - 1/16" x 4 x 24 sheet
• 5/16" x 5/16" x 36" balsa strips (2 pieces)
• 1/4" x 1/2" x 36" balsa strips (2 pieces)
• 3/16" x 3/16" x 36" balsa strips (4 pieces)
• 5/16" x 1-1/4" x 36" tapered balsa strips (2 pieces)
• 3/16" x 3/8" x 24" basswood strips (4 pieces)
• 1 - 1/4"x 6" wooden dowel
• 1 - 3/16"x 4" wooden dowel
Hardware parts included in this kit:
• Pre-bent main gear wire
• C/A type hinges for control surfaces
• 4 - control horns
• 2 - wheel collars 1/8" I.D.
• 2 - plastic gear straps
• 2 - 1/4"-20 wing bolts
Page 2
• Inspect your model before every flight to ensure it is airworthy.
• Be aware of any other radio frequency user who may present an
interference problem.
• Always be courteous and respectful of other users in your
selected flight area.
• Choose an area clear of obstacles and large enough to safely
accommodate your flying activity.
• Make sure this area is clear of friends and spectators prior to
launching your aircraft.
• Be aware of other activities in the vicinity of your flight path that
could cause potential conflict.
• Carefully plan your flight path prior to launch.
• Abide by any and all established AMA National Model Aircraft
Safety Codes.
IMPORTANT!!!
do to preserve the radio controlled aircraft hobby are to avoid flying
near full-scale aircraft and avoid flying near or over groups of people.
WARNING: This product can expose you to chemicals including lead, which
is known to the State of California to cause cancer and birth defects or other
reproductive harm. For more information go to www.P65Warnings.ca.gov.
• 10 - 2-56 x 1/2" machine screws
• 5 - 2-56 x 3/4" self tapping screws
• 4 - 1/4" Neodymium disc magnets
Other items included in this kit:
• 2 - Rolled plans (fuselage and wing)
• 1 - Construction Manual
• 1 - canopy
Hardware needed (not included in the kit)
For some of these items there is more than one option which will
require a bit of decision making ahead of time. There isn't a right or
a wrong choice, so choose the items that work best for you.
We strongly recommended supporting your local hobby shop.
• Powerplant:
if Electric (minimum 15-size, 840Kv brushless outrunner
motor, 30amp esc and 3-4S LiPo pack)
if Glow (.15-.30 engine, 6 ounce tank, fuel tubing)
• Propeller
• Engine/Motor mount and mounting hardware
• Receiver - (4 channel minimum)
• Sub-micro servos (4 for electric, 5 for glow) - 1 each for elevator
and rudder; 1 for each aileron 1 for throttle (if glow)
• "Y" servo harness (for ailerons)
• Pushrods (two 5" for ailerons, two 24" for elevator & rudder,
one 10" for throttle if glow powered)
• Clevises for the pushrods (8 if electric, 10 if glow).
• 2.5" diameter wheels
• Tailwheel assembly
• Covering
• Optional pilot figure for the cockpit.
Additional Required Building Tools and Adhesives
• Drill & assorted drill bits
