Included Items; Items Needed - Old School Model Works Javelin Construction Manual

WARNING
READ THROUGH THIS MANUAL
BEFORE STARTING CONSTRUCTION.
IT CONTAINS IMPORTANT WARNINGS
AND INSTRUCTIONS CONCERNING
THE CONSTRUCTION AND USE OF THIS
MODEL.
A Radio-Controlled aircraft is not a toy!
If misused, it can cause serious bodily harm
and damage to property. Fly only in open
areas, preferably at AMA (Academy of Model
Aeronautics) approved flying sites, following all
instructions included with your radio, powerplant,
electronics and batteries.

INCLUDED ITEMS

Wood parts included in this kit:
• 1 - LP1 - Laser Cut 1/8" x 6" x 24" ply sheet
• 1 - LP2 - Laser Cut 1/8" x 6" x 24" ply sheet
• 1 - LP3 - Laser Cut 1/8" x 6" x 24" ply sheet
• 1 - LP4 - Laser Cut 1/8" x 6" x 24" ply sheet
• 1 - LP5 - Laser Cut 1/8" x 6" x 24" ply sheet
• 1 - LP6 - Laser Cut 1/8" x 6" x 24" ply sheet
• 2 - BP1 - Laser Cut 1/8" x 4" x 24" balsa sheet
• 2 - BP2 - Laser Cut 1/8" x 4" x 24" balsa sheet
• 2 - BP3 - Laser Cut 1/8" x 4" x 24" balsa sheet
• 2 - BP4 - Laser Cut 1/8" x 4" x 24" balsa sheet
• 2 - BP5 - Laser Cut 1/8" x 4" x 24" balsa sheet
• 2 - BP6 - Laser Cut 1/8" x 4" x 24" balsa sheet
• 1 - BP7 - Laser Cut 1/8" x 4" x 24" balsa sheet
• 2 - BP8 - Laser Cut 1/16" x 4" x 24" balsa sheet
• 2 - BP9 - Laser Cut 1/16" x 4" x 24" balsa sheet
• 1 - BP10 - Laser Cut 1/16" x 4" x 24" balsa sheet
• 3 - 1/8" x 4" x 24" balsa sheet (uncut)
• 6 - 1/16" x 4" x 24" balsa sheet (uncut)
• 4 - 3/16" x 3/16" x 36" balsa strips
• 5 - 1/4" x 1/4" x 36" balsa strips
• 3 - 1/8" x 1/4" x 36" balsa strips
• 4 - 1/4" x 1/2" x 36" balsa strips
• 2 - 5/16" x 5/16" x 36" balsa strips
• 4 - 3/16" x 3/8" x 36" basswood strips
Hardware parts included in this kit:
• 1 - Pre-bent landing set (left & right)
• C/A type hinges for control surfaces
• 4 - control horns
• 2 - wheel collars 5/32" I.D.
• 2 - 5/32" axle shafts
Page 2
• Inspect your model before every flight to ensure it is airworthy.
• Be aware of any other radio frequency user who may present an
interference problem.
• Always be courteous and respectful of other users in your
selected flight area.
• Choose an area clear of obstacles and large enough to safely
accommodate your flying activity.
• Make sure this area is clear of friends and spectators prior to
launching your aircraft.
• Be aware of other activities in the vicinity of your flight path that
could cause potential conflict.
• Carefully plan your flight path prior to launch.
• Abide by any and all established AMA National Model Aircraft
Safety Codes.
IMPORTANT!!!
do to preserve the radio controlled aircraft hobby are to avoid flying
near full-scale aircraft and avoid flying near or over groups of people.
WARNING: This product can expose you to chemicals including lead, which
is known to the State of California to cause cancer and birth defects or other
reproductive harm. For more information go to www.P65Warnings.ca.gov.
• 2 - 5/16"-24 lock nuts
• 2 - 1/4 x 20 x 2" wing bolts
• 5 - 2-56 x 1/2" machine screws
• 4 - 2-56 x 3/4" machine screws
• 14 - 2-56 x 3/4" self tapping screws
• 10 - 4-40 x 1/2" socket head cap screws
• 2 - 4-40 x 1" socket head cap screws
• 6 - 4-40 lock nuts
• 6 - 4-40 t-nuts (blind nuts)
• 6 - #4 washers
• 4 - 1/4" x 1/8" neodymium magnets
• 1 - Pre-bent elevator joiner (1/8" music wire)
Other items included in this kit:
• 2 - Rolled plans (1 fuselage and 1 wing)
• 1 - Construction manual
• 1 - OSMW sticker sheet
Hardware needed (not included in the kit)
For some of these items there is more than one option which will
require a bit of decision making ahead of time. There isn't a right or
a wrong choice, so choose the items that work best for you.
Resist the urge to overpower the Javelin and remember that it is
not against the law to practice proper throttle management.
Here is a list of additional parts needed to complete and fly this
kit, all of which must be purchased separately. Again, we would
recommended supporting your local hobby shop.
• Powerplant:
Glow (.25-..51 engine, fuel tank, fuel tubing)
Electric (equivalent brushless motor, ESC, & batteries)
• Propeller
• Engine/Motor mount and mounting hardware
• Receiver - (4 channel minimum)
• 5 standard sized servos (4 if electric)
• "Y" servo harness and aileron servo wire extensions.
www.oldschoolmodels.com
Two of the most important things you can

ITEMS NEEDED

Construction Manual
