MWC25M-L2M-B20 series
Parameterization via J1939
Subin-
Index dex Designation
0x4100 0x16 Reflection 8
Distance
0x17 Reflection 8
Velocity
0x18 Reflection 8
Amplitude
Table 8.16
Subin-
Index dex Designation
0x4100 0x19 Reflection 9
Distance
0x1A Reflection 9
Velocity
0x1B Reflection 9
Amplitude
Table 8.17
Subin-
Index dex Designation
0x4100 0x1C Reflection 10
Distance
0x1D Reflection 10
Velocity
0x1E Reflection 10
Amplitude
Table 8.18
Subin-
Index dex Designation
0x4100 0x1F Get All
Table 8.19
Attri-
Data Type bute Default Value
real32 ro -
real32 ro -
real32 ro -
Attri-
Data Type bute Default Value
real32 ro -
real32 ro -
real32 ro -
Attri-
Data Type bute Default Value
real32 ro -
real32 ro -
real32 ro -
Attri-
Data Type bute Default Value
array8 ro
Meaning
Contains the distance value
of the eighth reflection in mm
Contains the velocity value of
the eighth reflection in cm/s
Contains the amplitude value
of the eighth reflection in dig-
its
Meaning
Contains the distance value
of the ninth reflection in mm
Contains the velocity value of
the ninth reflection in cm/s
Contains the amplitude value
of the ninth reflection in digits
Meaning
Contains the distance value
of the tenth reflection in mm
Contains the velocity value of
the tenth reflection in cm/s
Contains the amplitude value
of the tenth reflection in digits
Meaning
Contains all reflections at
once. You need to convert the
values from "Bytes" to the
"Float" data type.
