Pepperl+Fuchs MWC25M-L2M-B20 Series Manual
  1. Manuals
  2. Brands
  3. Pepperl+Fuchs Manuals
  4. Security Sensors
  5. MWC25M-L2M-B20 Series
  6. Manual
Pepperl+Fuchs MWC25M-L2M-B20 Series Manual

Pepperl+Fuchs MWC25M-L2M-B20 Series Manual

Parameterization of radar sensors with can sae j1939 interface
Hide thumbs Also See for MWC25M-L2M-B20 Series:

Advertisement

Quick Links

Download this manual
MWC25M-L2M-B20 Series
Parameterization of
Radar Sensors with
CAN SAE J1939 Interface
Manual

Advertisement

loading
Need help?

Need help?

Do you have a question about the MWC25M-L2M-B20 Series and is the answer not in the manual?

Questions and answers

Subscribe to Our Youtube Channel

Related Manuals for Pepperl+Fuchs MWC25M-L2M-B20 Series

Summary of Contents for Pepperl+Fuchs MWC25M-L2M-B20 Series

  • Page 1 MWC25M-L2M-B20 Series Parameterization of Radar Sensors with CAN SAE J1939 Interface Manual...
  • Page 2 Phone: +49 621 776 - 0 E-mail: info@de.pepperl-fuchs.com North American Headquarters Pepperl+Fuchs Inc. 1600 Enterprise Parkway Twinsburg, Ohio 44087 Phone: +1 330 425-3555 E-mail: sales@us.pepperl-fuchs.com Asia Headquarters Pepperl+Fuchs Pte. Ltd. P+F Building 18 Ayer Rajah Crescent Singapore 139942 Phone: +65 6779-9091 E-mail: sales@sg.pepperl-fuchs.com https://www.pepperl-fuchs.com...

  • Page 3: Table Of Contents

    MWC25M-L2M-B20 series Contents Introduction........................ 6 Content of this Document ................6 Target Group, Personnel ................6 Symbols Used ....................6 Intended Use ....................7 General Safety Information................8 Declaration of Conformity................9 Declaration of Conformity FCC, Canada ............. 9 Product Description ....................11 Use and Application ..................
  • Page 4 MWC25M-L2M-B20 series Contents Commissioning ......................23 Commissioning via PACTwareDC and DTM ..........23 Commissioning via CAN Engineering Tool..........26 6.2.1 Processing the Process Data .................... 27 6.2.2 Changing the Device Address................... 28 6.2.3 Writing parameters......................28 Transfer rate ........................28 6.2.4 6.2.5 Evaluate Error Messages ....................28 6.2.6...
  • Page 5 MWC25M-L2M-B20 series Contents Maintenance and Repair ..................52 Maintenance Work ..................52 Cleaning......................52 Troubleshooting....................... 53 10.1 What to Do in Case of Fault ................ 53...

  • Page 6: Introduction

    MWC25M-L2M-B20 series Introduction Introduction Content of this Document This document contains information required to use the product in the relevant phases of the product life cycle. This may include information on the following: • Product identification • Delivery, transport, and storage •...

  • Page 7: Symbols Used

    MWC25M-L2M-B20 series Introduction Symbols Used This document contains symbols for the identification of warning messages and of informative messages. Warning Messages You will find warning messages, whenever dangers may arise from your actions. It is mandatory that you observe these warning messages for your personal safety and in order to avoid prop- erty damage.

  • Page 8: Intended Use

    Note Radar sensors in the MWC25M-L2M-B20 series are only approved in the countries listed in the relevant declaration of conformity for the radar sensor. These can be found online at www.pepperl-fuchs.com on the respective product page for the sensor version of the MWC25M-L2M-B20 series.

  • Page 9: General Safety Information

    If serious faults occur, stop using the device. Secure the device against inadvertent operation. In the event of repairs, return the device to your local Pepperl+Fuchs representative or sales office.

  • Page 10: Declaration Of Conformity Fcc, Canada

    MWC25M-L2M-B20 series Introduction Declaration of Conformity FCC, Canada The product manufacturer, Pepperl+Fuchs Group, 68307 Mannheim, Germany, has a certified quality assurance system that conforms to ISO 9001. This device contains licence-exempt transmitter(s)/receiver(s) that comply with Innovation, Sci- ence and Economic Development Canada’s licence-exempt RSS(s) and complies with part 15 of the FCC Rules.

  • Page 11: Product Description

    Product Description Use and Application The MWC25M-L2M-B20 series radar sensor with J1939 interface for medium distances up to 25 m detection range is optimized for use in industrial applications. Its compact cubic L2 series housing is proven in many industrial areas due to its high robustness.
  • Page 12 The latest available versions of the individual software compo- nents required, such as the "CAN Parameterization Tool" and the device DTM, can be found online at www.pepperl-fuchs.com, on the product page for the MWC25M-L2M-B20 series. Availability of a DBC file A DBC file (database container) is available for integrating and parameterizing the radar sen- sor.

  • Page 13: Measurement Characteristics

    Safety Applications Radar sensors in the MWC25M-L2M-B20 series can be used in safety applications under cer- tain circumstances, taking into account certain aspects up to PL c in combination with a diag- nostics-enabled controller (e.g., PLC).

  • Page 14: Indicators

    MWC25M-L2M-B20 series Product Description Indicators The radar sensor has multi-color LEDs, each with three colors, for displaying operating and sta- tus information. Two LEDs with the same meaning are arranged diagonally on the device to ensure better visi- bility in an application environment.
  • Page 15 MWC25M-L2M-B20 series Product Description STATUS LED (red) LED status Description The device is in the state "CAN Bus Off" The device is operating without errors Rapid flashing The "address claiming" failed, no address has been assigned to the device and it does not participate in bus communication (flashing fre- quency 10 Hz).

  • Page 16: Supported J1939 Functions

    MWC25M-L2M-B20 series Product Description Supported J1939 Functions The device has a standardized J1939 interface to SAE J1939-21 and SAE J1939-81 specifica- tions. Usable objects of object directory OV are listed in this manual. The address is assigned with "Address Claiming" at start-up. The start value is 128. If the claim is unsuccessful, the address is incremented and the "Claiming Process"...

  • Page 17: Accessories

    2.6.1 Connection Accessories Various connecting cables and cordsets are available for connecting the sensors of the MWC25M-L2M-B20 series. You will find details online at www.pepperl-fuchs.com on the product page for the relevant sensor or on the relevant datasheet. Note For mounting, connection, and commissioning, the following product information is available online at www.pepperl-fuchs.com on the product page for the relevant sensor: datasheet,...

  • Page 18: Parameterization Aids

    DTM for CAN communication • VCI driver for the CAN/USB converter-SUBD9 Visit www.pepperl-fuchs.com and access the product page for the rele- vant sensor in the MWC25M-L2M-B20 series DTM for DTM (Device Type Manager)—device description and graphic user inter- MWC25M-L2M- face for radar sensor parameterization, integration into the system envi-...
