Field Attributes
• MAC Address – Physical address of a device mapped to this interface.
• Port Num – Port associated with the device assigned a static address.
• Vlan ID – ID of configured VLAN (1-4094). This option is only
available if IEEE 802.1Q tagged VLANs are enabled (page 4-23).
Console – Click Switch Static Configuration=>MAC Address
Configuration=>Static MAC Address. Click <Add> to open the Add Static
MAC Address page. Specify the MAC address, port number, and VLAN
ID, then save your settings.
Tiger Switch 10/100 6709GL2 : Add Static MAC Address
===========================
actions->
Tab=Next Item BackSpace=Previous Item
After you configure a new address, it will be displayed on the Static MAC
Address Configuration page as shown below.
Mac Address :0030299434DE
Port num :2
Vlan ID :1
<Edit>
Save successfully!Press any key to return!
S S
WITCH TATIC
<Save>
Quit=Previous Menu
C
ONFIGURATION
<Quit>
Enter=Select Item
M
ENU
4-29
