C I
ONSOLE NTERFACE
• Forward Delay Time – The maximum time (in seconds) the root
device will wait before changing states (i.e., listening to learning to
forwarding). This delay is required because every device must receive
information about topology changes before it starts to forward frames.
In addition, each port needs time to listen for conflicting information
that would make it return to a blocking state; otherwise, temporary data
loops might result.
- Default: 15
- Minimum: The higher of 4 or [(Max. Message Age / 2) + 1]
- Maximum: 30
Console – Click Protocol Related Configuration=>STP=>System
Configuration. Modify the required attributes, and save your settings
Root Bridge Information
------------------------
Priority
Mac Address
Root_Path_Cost: 10
Root Port
Max Age
Hello Time
Forward Delay : 15
actions->
Tab=Next Item
4-44
Tiger Switch 10/100 6709GL2 : STP System Configuration
===========================
: 32768
: 0000ABCD0000
: 2
: 20
: 2
<Edit>
Select the action menu.
BackSpace=Previous Item
Configure Spanning Tree Parameters
-----------------------------------
Priority (1-65535)
Max Age (6-40)
Hello Time (1-10)
Forward_Delay_Time(4-30)
<Save>
Quit=Previous Menu
:32768
:20
:2
:15
<Quit>
Enter=Select Item
