I C
NITIAL ONFIGURATION
To assign an IP address to the switch, complete the following steps:
1. Navigate from the Main Menu to –
2. Select <Edit>, type in the IP Address, Subnet Mask, and Gateway.
Press <Enter> after each item. Press <Ctrl-A> to return to the action
bar at the bottom of the screen. Select <Save> and press any key to
continue. (The IP addresses shown below are merely examples.)
actions->
Tab=Next Item BackSpace=Previous Item Quit=Previous menu Enter=Select Item
3. Navigate back to the Main Menu, go to Reboot Switch menu, select
the "Restart" command, and press <Enter>.
2-6
Switch Static Configuration,
Administration Configuration, and then
IP Configuration.
Tiger Switch 10/100 6709GL2 : IP Configuration
===========================
IP Address
Subnet Mask : 255.255.255.0
Gateway
<Edit>
: 192.168.16.1
: 192.168.16.254
<Save>
Select the action menu.
<Quit>
