SMC Networks TigerSwitch SMC6709FL2 Installation Manual

Tigerswitch 10/100 9-port fast ethernet switch
Hide thumbs Also See for TigerSwitch SMC6709FL2:
Table of Contents

Advertisement

Quick Links

Download this manual
TigerSwitch 10/100
9-Port Fast Ethernet Switch
8 10BASE-T/100BASE-TX ports, 1 100BASE-FX
MMF port
1.8 Gbps aggregate bandwidth
Spanning Tree Protocol
Port mirroring for non-intrusive analysis
QoS support with two priority queues
Full support for VLANs with GVRP
IP multicasting with IGMP snooping
Security filtering based on MAC addresses
Manageable via console, Web, SNMP/RMON

Installation Guide

SMC6709FL2

Advertisement

Table of Contents
loading
Need help?

Need help?

Do you have a question about the TigerSwitch SMC6709FL2 and is the answer not in the manual?

Questions and answers

Subscribe to Our Youtube Channel

Related Manuals for SMC Networks TigerSwitch SMC6709FL2

Summary of Contents for SMC Networks TigerSwitch SMC6709FL2

  • Page 1: Installation Guide

    TigerSwitch 10/100 9-Port Fast Ethernet Switch 8 10BASE-T/100BASE-TX ports, 1 100BASE-FX MMF port 1.8 Gbps aggregate bandwidth Spanning Tree Protocol Port mirroring for non-intrusive analysis QoS support with two priority queues Full support for VLANs with GVRP IP multicasting with IGMP snooping...
  • Page 3 TigerSwitch 10/100 Installation Guide From SMC’s Tiger line of feature-rich workgroup LAN solutions 38 Tesla Irvine, CA 92618 Phone: (949) 679-8000 February 2004...
  • Page 4 Information furnished by SMC Networks, Inc. (SMC) is believed to be accurate and reliable. However, no responsibility is assumed by SMC for its use, nor for any infringements of patents or other rights of third parties which may result from its use. No license is granted by implication or otherwise under any patent or patent rights of SMC.

  • Page 5: Limited Warranty

    All SMC products carry a standard 90-day limited warranty from the date of purchase from SMC or its Authorized Reseller. SMC may, at its own discretion, repair or replace any product not operating as warranted with a similar or functionally equivalent product, during the applicable warranty term.
  • Page 6 RIGHTS, WHICH MAY VARY FROM STATE TO STATE. NOTHING IN THIS WARRANTY SHALL BE TAKEN TO AFFECT YOUR STATUTORY RIGHTS. * SMC will provide warranty service for one year following discontinuance from the active SMC price list. Under the limited lifetime warranty, internal and external power supplies, fans, and cables are covered by a standard one-year warranty from date of purchase.

  • Page 7: Industry Canada - Class A

    Warnings: 1. Wear an anti-static wrist strap or take other suitable measures to prevent electrostatic discharge when handling this equipment. 2. When connecting this switch to a power outlet, connect the field ground lead on the tri-pole power plug to a valid earth ground line to prevent electrical hazards.
  • Page 8 OMPLIANCES EC Conformance Declaration - Class A SMC contact for these products in Europe is: SMC Networks Europe, Edificio Conata II, Calle Fructuós Gelabert 6-8, 2 08970 - Sant Joan Despí, Barcelona, Spain. This information technology equipment complies with the requirements of the Council...

  • Page 9: Safety Compliance

    Safety Compliance Warning: Fiber Optic Port Safety CLASS I LASER DEVICE Avertissment: Ports pour fibres optiques - sécurité sur le plan optique DISPOSITIF LASER DE CLASSE I Warnhinweis: Faseroptikanschlüsse - Optische Sicherheit LASERGER ÄT DER KLASSE I Underwriters Laboratories Compliance Statement Important! Before making connections, make sure you have the correct cord set.

  • Page 10: Wichtige Sicherheitshinweise (Germany)

    OMPLIANCES Wichtige Sicherheitshinweise (Germany) 1. Bitte lesen Sie diese Hinweise sorgfältig durch. 2. Heben Sie diese Anleitung für den späteren Gebrauch auf. 3. Vor jedem Reinigen ist das Gerät vom Stromnetz zu trennen. Verwenden Sie keine Flüssigoder Aerosolreiniger. Am besten eignet sich ein angefeuchtetes Tuch zur Reinigung.

  • Page 11: Table Of Contents

    Overview ..........1-1 Switch Architecture ........1-2 Switching Method .
  • Page 12 Troubleshooting ......A-1 Diagnosing Switch Indicators ....... . . A-1 Power and Cooling Problems .
  • Page 13 Overview SMC’s TigerSwitch™ 10/100, SMC6709FL2, is an intelligent standalone Fast Ethernet switch with 8 10BASE-T/100BASE-TX Mbps ports and 1 100BASE-FX multi-mode port. There is also an SNMP-based management agent embedded on the main board. This agent supports both in-band and out-of-band access for managing the switch.

  • Page 14: About The Tigerswitch 10/100

    The TigerSwitch 10/100 employs a wire-speed, non-blocking switching fabric. This permits simultaneous wire-speed transport of multiple packets at low latency on all ports. This switch also features full-duplex capability on all ports, which effectively doubles the bandwidth of each connection.

  • Page 15: Description Of Hardware

    100BASE-FX MMF Port There is one fixed 100BASE-FX MMF fiber port on the switch’s front panel. The fiber connector is SC multi-mode. The distance for fiber cabling can be extended to up to two kilometers.

  • Page 16: Tigerswitch 10/100 Fiber Port

    BOUT THE IGER WITCH Status Power 10/100 Link/ Blinks FDX/ Blinks TigerSwitch 10/100 fiber port The fiber connector available on the TigerSwitch 10/100 is an SC multi-mode connector. It is listed in the below figure. 10/100 TigerSwitch 10/100 6709FL2 10/100 System Status LEDs Color Green...

  • Page 17: 100Base-Fx Port

    2Km (6561 ft) away. Power Supply Receptacle There is a power receptacle on the rear panel of the switch for the AC power cord. Figure 1-3. Power Supply Receptacle...

  • Page 18: Auto Mdi/Mdi-X

    BOUT THE IGER WITCH manually Independent RJ-45 10BASE-T/100BASE-TX ports with support for auto MDI/MDI-X Unshielded (UTP) cable supported on all RJ-45 ports: Category 3, 4 or 5 for 10 Mbps connections, Category 5 for 100 Mbps connections Complies with IEEE 802.3 Ethernet, 802.3u Ethernet and 802.3x Ethernet standards Fiber Connectivity Single-port 100BASE-FXMMF multimode fibre port that can run a...

  • Page 19: Management

    Management “At-a-glance” LEDs for easy troubleshooting Network management agent: • Manages switch in-band or out-of-band • Supports Telnet, SNMP/RMON and Web-based interface • Spanning Tree Protocol for redundant network connections • VLAN Support with up to 128 groups, port-based or with 802.1Q VLAN tagging, and GVRP for automatic VLAN learning •...
  • Page 20 10/100 BOUT THE IGER WITCH...

  • Page 21: Network Planning

    For Ethernet, there may be up to four hubs between any pair of stations; for Fast Ethernet, the maximum is two. This is known as the hop count. However, a switch turns the hop count back to zero, so subdividing the network into smaller and more manageable segments, and linking them to the larger network by means of a switch, removes this limitation.

  • Page 22: Application Examples

    When the time comes for further expansion, just cascade the TigerSwitch 10/100 to an Ethernet or Fast Ethernet hub or switch. In the figure below, the TigerSwitch 10/100 is operating as a collapsed backbone for a small LAN. It is providing dedicated 20 Mbps full-duplex connections to workstations and 200 Mbps full-duplex connections to power users and servers.

  • Page 23: Remote Connections With Fiber Cable

    100BASE-FX MMF connector can be used to interconnect remote Fast Ethernet segments. The figure below illustrates a TigerSwitch 10/100 connecting multiple segments with fiber cable. Server Farm Remote Switch Figure 2-2. Collapsed Backbone Using Fiber Cable Headquarters TigerSwitch 10/100 6709FL2...

  • Page 24: Making Vlan Connections

    VLAN group it belongs to. When using port-based VLANs, ports can either be assigned to one specific group or to all groups. Port-based VLANs are suitable for small networks. A single switch can be easily configured to support several VLAN groups for various organizational entities (such as Finance and Marketing).

  • Page 25: Connectivity Rules

    Ethernet and Fast Ethernet. However, note that because switches break up the path for connected devices into separate collision domains, you should not include the switch or connected cabling in your calculations for cascade length involving other devices.

  • Page 26: Application Notes

    When the switch is connected to a hub, both devices must operate in half-duplex mode. 2. When a switch is connected to a hub or any kind of shared media, remember to turn off back pressure to prevent jamming packets from being propagated throughout the hub.

  • Page 27: Installing The Switch

    NSTALLING THE Selecting a Site TigerSwitch 10/100 units can be mounted on a flat surface. Be sure to follow the guidelines below when choosing a location. The site should: • be at the center of all the devices you want to link and near a power outlet.

  • Page 28: Equipment Checklist

    Management Guide One set of rack mount kit SMC Warranty Registration Card—be sure to complete and return to Note: The package equipment contents include three types of power cord. The power cords are for the EU, UK and US. Please ensure...

  • Page 29: Mounting

    Mounting Desktop or Shelf Mounting 1. Attach the four adhesive feet to the bottom of the first switch. Figure 3-1. Attaching the Adhesive Feet 2. Set the device on a flat surface near an AC power source, making sure there are at least two inches of space on all sides for proper air flow.
  • Page 30 NSTALLING THE WITCH receptacle located at the back of the device. 2. Plug the other end of the cable into a grounded, 3-pin socket. Note: For International use, you may need to change the AC line cord. You must use a line cord set that has been approved for the receptacle type in your country.

  • Page 31: Making Network Connections

    Connecting Network Devices The TigerSwitch 10/100 is designed to interconnect multiple segments (or collision domains). It may be connected to network cards in PCs and servers, as well as to hubs, switches or routers. Note: Before connecting cables, you may want to first configure the Spanning Tree Protocol to avoid network loops.

  • Page 32: Cabling Guidelines

    AKING ETWORK Cabling Guidelines The RJ-45 ports on the switch support automatic MDI/MDI-X operation, so you can use standard straight-through twisted-pair cables to connect to any other network device (PCs, servers, switches, routers, or hubs). See Appendix B for further information on cabling.

  • Page 33: Fiber Optic Devices

    SC connector at both ends. If you need to connect to a device with 62.5/125 micron cable that has ST-type connectors, SMC provides an optional SC-ST Converter (Part Number: 99-012034-091). Caution: This switch uses lasers to transmit signals over fiber optic cable.
  • Page 34 AKING ETWORK 3. Connect one end of the cable to the SC port on the switch and the other end to the SC port on the other device. Since SC connectors are keyed, the cable can be attached in only one orientation.

  • Page 35: Troubleshooting

    Contact SMC Tech Support. • Verify that the switch and attached device are powered • Be sure the cable is plugged into both the switch and corresponding device. • Verify that the proper cable type is used and its length does not exceed specified limits.

  • Page 36: Power And Cooling Problems

    If you still cannot isolate the problem, contact SMC Technical Support for assistance.

  • Page 37: Specifications

    62.5/125 micron 50/125 micron MMF Note: If you need to connect to a device with 62.5/125 micron cable that has ST-type connectors, SMC provides an optional SC-ST Converter (Part Number: 99-012034-091). Twisted-Pair Cable and Pin Assignments Caution: DO NOT plug a phone jack connector into any RJ-45 port.

  • Page 38: Cables

    ABLES For 100BASE-TX/10BASE-T connections, a twisted-pair cable must have two pairs of wires. Each wire pair is identified by two different colors. For example, one wire might be red and the other, red with white stripes. Also, an RJ-45 connector must be attached to both ends of the cable. Caution: Each wire pair must be attached to the RJ-45 connectors in a specific orientation.

  • Page 39: Twisted-Pair Cable And Pin Assignments

    1: The “+” and “-” signs represent the polarity of the wires that make up each wire pair. Because all ports on this switch support automatic MDI/MDI-X operation, you can use straight-through cables for all network connections to PCs or servers, or to other switches or hubs. In straight-through cable, pins 1, 2, 3, and 6, at one end of the cable, are connected straight through to pins 1, 2, 3 and 6 at the other end of the cable.

  • Page 40: Console Port Pin Assignments

    ABLES Console Port Pin Assignments The DB-9 serial port on the switch’s front panel is used to connect to the switch for out-of-band console configuration. The on-board menu-driven configuration program can be accessed from a terminal or a PC running a terminal emulation program.

  • Page 41: Console Port To 25-Pin Dte Port On Pc

    Console Port to 25-Pin DTE Port on PC Switch’s 9-Pin Serial Port 2 RXD 3 TXD 5 SGND No other pins are used. ONSOLE Null Modem <---------RXD ------------ -----------TXD ----------> -----------SGND ---------- SSIGNMENTS PC’s 25-Pin DTE Port 2 TXD 3 RXD...
  • Page 42 ABLES...

  • Page 43: Specifications

    Physical Characteristics Ports 8 10BASE-T/100BASE-TX ports, with auto-negotiation 1 100BASE-FX port 1 Console port Network Interface Ports 1-8: RJ-45 connector, auto MDI/MDI-X 10BASE-T: RJ-45 (100-ohm, UTP cable; Categories 3, 4, 5) 100BASE-TX: RJ-45 (100-ohm, UTP cable; Category 5) Port 9: Fiber SC connector 100BASE-FX MMF: SC connector (62.5/125 or 50/125 microns- -cable) Buffer Architecture...

  • Page 44: Compliances

    PECIFICATIONS Size 25.0 x 38.0 x 13.2 cm (10.0 x 5.25 x 1.75 in.) Temperature Operating: 0 to 45 Storage: -40 to 70 Humidity Operating: 10% to 90% AC Input 100 to 240 V, 50 to 60 Hz Power Supply Internal, auto-ranging transformer: 100 to 240 VAC, 47 to 63 Hz Power Consumption 19 Watts maximum...

  • Page 45: Fiber Port

    Fiber Port 100BASE-FX MMF port Port 1 100BASE-FX fiber port Network Interface SC connector, 50/125 or 62.5/125 micron multimode fiber cable Standards IEEE 802.3u Fast Ethernet PECIFICATIONS...
  • Page 46 PECIFICATIONS...

  • Page 47: Glossary

    10BASE-T IEEE 802.3 specification for 10 Mbps Ethernet over two pairs of Category 3, 4, or 5 UTP cable. 100BASE-TX IEEE 802.3u specification for 100 Mbps Fast Ethernet over two pairs of Category 5 UTP cable. 100BASE-FX IEEE 802.3u specification for 100 Mbps Fast Ethernet over two strands of 50/125 or 62.5/125 micron core fiber cable.
  • Page 48 LOSSARY CSMA/CD CSMA/CD (Carrier Sense Multiple Access/Collision Detect) is the communication method employed by Ethernet, Fast Ethernet, or Gigabit Ethernet. End Station A workstation, server, or other device that does not forward traffic. Ethernet A network communication system developed and standardized by DEC, Intel, and Xerox, using baseband transmission, CSMA/CD access, logical bus topology, and coaxial cable.
  • Page 49 access method and physical layer specifications. IEEE 802.3ab Defines CSMA/CD access method and physical layer specifications for 1000BASE-T Fast Ethernet. IEEE 802.3u Defines CSMA/CD access method and physical layer specifications for 100BASE-TX Fast Ethernet. IEEE 802.3x Defines Ethernet frame start/stop requests and timers used for flow control on full-duplex links.
  • Page 50 LOSSARY nodes. An acronym for Management Information Base. It is a set of database objects that contains information about the device. Network Diameter Wire distance between two end stations in the same collision domain. RJ-45 Connector A connector for twisted-pair wiring. Straight-through Port An RJ-45 port which does not cross the receive and transmit signals internally (MDI) so it can be connected with straight-through twisted-pair...

  • Page 51: Index

    Numerics 10 Mbps connectivity rules 2-6 100BASE cable lengths 2-6 100BASE-FX C-4 connections 4-4 10BASE cable lengths 2-6 accessories, ordering D-1 adhesive feet, attaching 3-4 air flow requirements 3-1 applications 2-2 central wiring closet 2-3 collapsed backbone 2-2 examples 2-2 remote connections with fiber 2-3 VLAN connections 2-4 broadcast storm control 1-2...
  • Page 52 NDEX installation connecting devices to the switch 4-2 desktop or shelf mounting 3-6 port connections 4-1 power requirements 3-1 problems A-2 rack mounting 3-3 site requirements 3-1 wiring closet connections 4-3 laser safety 4-4 layer-3 routing 1-2 LED indicators Power 1-5...
  • Page 53 2-1 method 1-2 tags, VLAN 2-4 Telnet A-2 temperature within a rack 3-3 troubleshooting in-band access A-2 power and cooling problems A-2 switch indicators A-1 twisted-pair connections 4-1 VLANs 1-2 tagging 2-4 warranty C-2 Web-based management 1-2 NDEX Index-3...
  • Page 54 NDEX Index-4...
  • Page 56 Taiwan: Asia Pacific: Korea: Japan: Australia: India: Middle East: Thailand: If you are looking for further contact information, please visit www.smc.com, www.smc-europe.com, or www.smc-asia.com. 38 Tesla Irvine, CA 92618 Phone: (949) 679-8000 (800) SMC-4-YOU; Fax (949) 679-1481 34-93-477-4935; Fax 34-93-477-3774 44 (0) 118 974 8700;...
