State Activity
LACP Status

Configuring the Aggregator Setting

First use the Port Configuration page to create trunk groups (page 4-16),
and then use the Aggregator Setting page to enable LACP and specify the
maximum number of active ports.
Field Attributes
• Group – Specifies the LACP trunk group.
• LACP – Set this field to "Enabled" when configuring a dynamic trunk.
• LACP Work Port Num – Specifies the number of active ports. If the
number of active ports is less than the number of assigned members,
excess ports will be placed in standby mode and only brought into
service if an active link fails.
Console – Click Protocol Related Configuration=>LACP=>Aggregator
Setting. Select the required trunk group, enable LACP, enter the number of
active ports, and then save your settings.
P R
ROTOCOL ELATED
Description
Actively or passively configures a trunk
Shows trunks and associated ports, and
detailed information for dynamic links
C
ONFIGURATION
M
ENU
Page
4-55
4-56
4-53
