Configuring Address Aging

Use the MAC Age Interval page to set the address aging time. The switch
stores the addresses of known devices. This information is used to route
traffic directly between the inbound and outbound ports. The addresses
are learned by monitoring traffic and stored in the dynamic address table.
You can set the aging time after which inactive entries are removed.
(Range: 300-765 seconds; Default: 300 seconds)
Console – Click Switch Static Configuration=>Misc
Configuration=>MAC Age Interval. Specify the aging time, and save your
settings.
Tiger Switch 10/100 6709GL2 : The Configuration of Aging Time
===========================
MAC Age Interval (sec) [300
actions->
Tab=Next Item BackSpace=Previous Item
<Edit>
Select the action menu.
S S
WITCH TATIC
] : 300 (300~765)
<Save>
Quit=Previous Menu
C
ONFIGURATION
<Quit>
Enter=Select Item
M
ENU
4-35
