Back of the Switch
.
Power Connector
The SMC6624M does not have a power switch; it is powered on when
connected to an active AC power source. The switch automatically adjusts to
any voltage between 100-127 and 200-240 volts and either 50 or 60 Hz. There
are no voltage range settings required.
Introducing the TigerSwitch 10/100 SMC6624M
cooling vent - make sure this is not
obstructed for proper switch operation
Back of the Switch
Line:50/60Hz
100-127V
~ 2.4A
200-240V 1.2A
~
AC power connector
1-5
