Introducing the TigerSwitch 10/100 SMC6624M

Front of the Switch

Front of the Switch
Link and Act LEDs
for switch ports
25 26 1 2 3 4 5 6 13 14 15 16 17 18
Console
Power
7 8 9 10 11 12 19 20
Fault
Self Fan
Reset Clear
Test Status
Console
port
Reset and Clear
Power
buttons
and Fault
LEDs

Network Ports

I
I
1-2
Slots for
Gigabit or 100 Mbps
modules
Link
25
Act
Link
Act
21 22 23 24
Self Test and Fan
Status LEDs
24 autosensing 10/100Base-TX ports.
All these ports support Auto MDI/MDI-X, which means that you can use
either straight-through or crossover twisted-pair cables to connect any
network devices to the switch.
Two module slots for installing any of the supported gigabit and 100 Mbps
modules.
1 2 3 4 5
26
7 8 9 10 11
10/100Base-TX RJ-45 Auto MDI/MDI-X ports
6
13 14 15 16 17 18
12
19 20 21 22 23 24
