Charder HM80DT User Manual

Digital infant stadiometer

Advertisement

Quick Links

Height Measurement
USER MANUAL
HM80DT
Digital Infant Stadiometer
Please keep the instruction manual at hand and follow instruction for use.

Advertisement

Table of Contents
loading
Need help?

Need help?

Do you have a question about the HM80DT and is the answer not in the manual?

Questions and answers

Subscribe to Our Youtube Channel

Summary of Contents for Charder HM80DT

  • Page 1 Height Measurement USER MANUAL HM80DT Digital Infant Stadiometer Please keep the instruction manual at hand and follow instruction for use.
  • Page 2: Table Of Contents

    CONTENTS I. Explanation of Text/Symbols on Device Label/Packaging ..3 II. Copyright Notice ..............5 III. Safety Notes ................6 A. General Information ............. 6 B. EMC Guidance and Manufacturer's Declaration ....9 IV. Installation ................4 A.Assembly with MS5980 Infant Scale......... 4 B.
  • Page 3: Explanation Of Text/Symbols On Device Label/Packaging

    I. Explanation of Text/Symbols on Device Label/Packaging Text/Symbol Meaning Caution, consult accompanying documents before use Separate collection for waste of electrical and electronic equipment, in accordance with Directive 2002/96/EC. Do not dispose of device with everyday waste Name and address of device manufacturer, and year/country of manufacture Carefully read user manual before installation and usage, and follow instructions for use.
  • Page 4 Device complies with EC directives (verified models only) M: Conformity label in compliance with Directive 2014/31/EU for non-automatic weighing instruments 20: Year in which conformity verification was performed and the CE label was applied. (ex: 16=2016) 0122: Identifier for metrology Notified Body Device is a Class III scale in compliance with Directive 2014/31/EU (verified models only) Name and address of entity importing device (if...
  • Page 5: Copyright Notice

    Copyright© Charder Electronic Co., Ltd. All rights reserved. This user manual is protected by international copyright law. All content is licensed, and usage is subject to written authorization from Charder Electronic Co., Ltd. (hereinafter Charder) Charder is not liable for any damage caused by a failure to adhere to requirements stated in this manual.
  • Page 6: Safety Notes

    III. Safety Notes A. General Information Thank you for choosing this Charder Medical device. It is designed to be easy and straightforward to operate, but if you encounter any problems not addressed in this manual, please contact your local Charder service partner.
  • Page 7 Cleaning Device surface should be cleaned using alcohol-based wipes.  Maintenance Please contact your local Charder distributor for regular maintenance and calibration, regular checking of accuracy is recommended; frequency to be determined by level of use and state of device.
  • Page 8 Charder service partner, using original Charder accessories and spare parts. Charder is not liable for any damages arising from improper maintenance or usage. Dismantlement of the device will void the warranty.
  • Page 9: Emc Guidance And Manufacturer's Declaration

    B. EMC Guidance and Manufacturer's Declaration Guidance and manufacturer’s declaration-electromagnetic emissions The product isintended for use in the electromagnetic environment specified below. The customer or the user of the product should assure that it is used in such an environment. Emission test Compliance Electromagnetic...
  • Page 10 Guidance and manufacturer’s declaration-electromagnetic immunity The product is intended for use in the electromagnetic environment specified below. The customer or the user of the product should assure that it is used in such an environment. Immunity IEC 60601 Compliance level Electromag test level netic...
  • Page 11 NOTE UT is the a.c. mains voltage prior to application of the testlevel. Guidance and manufacturer’s declaration-electromagnetic immunity Theproduct is intended for use in the electromagnetic environment specified below. The customer or the user of the product should assure that is used in such and environment. Immunity test IEC 60601 test Compliance...
  • Page 12 Field strengths from fixed transmitters, such as base stations for radio (cellular/cordless) telephones and land mobile radios,amateurradio,AMandFMradiobroadcastandTVbroadcastcannotbepredictedtheo reticallywithaccuracy.To assess the electromagnetic environment due to fixed RF transmitters, an electromagnetic site survey should be considered. If the measured field strength in the location in which the product is used exceedstheapplicable RF compliance level above, the product should be observed to verify normal operation.
  • Page 13: Installation

    IV. Installation A.Assembly with MS5980 Infant Scale 1、Align end of stadiometer with 2nd protruding point on stopper. 2、Press two parts together, and then push stopper inwards 3、Stopper assembly complete (repeat steps 1-3 for other side)
  • Page 14 4. Install height rod + headstopper onto bracket using Philips screws 5. Line up "A" on Stadiometer with "B" on Column...
  • Page 15 6. Install height rod + headstopper + bracket onto infant scale. (Twist knobs clockwise to secure bracket). 7. Plug data transmission port into indicator. 8. Fasten screw on front of column...
  • Page 16 Assembly complete...
  • Page 17: Assembly With Ms3500 And Ms21Neov Infant Scale

    B. Assembly with MS3500 and MS21NEOV Infant Scale 1. Attach bracket to tray using bracket screws*2 2. Connect HM80DT cable to scale.
  • Page 18: Using Device

    V. Using Device A. Calibrating Height Stadiometer Before using height stadiometer, slide measurement rod to left completely then turn on scale to finish calibration. B. Performing measurement and operating 1. Lay infant on flat platform, with head touching head stopper. Straighten infant’s feet.
  • Page 19 2. Use right hand to push foot stopper until it touches soles of infant's feet. You can also read measurement result from stadiometer. The height measurement result will automatically be sent to device indicator and display at the same time.
  • Page 20: Product Specifications

    1/16 in Accuracy ± 10 mm Dimensions Overall 870(W) x 290(D) x 70(H) mm Device Weight 0.5 kg Operation Environment +5℃~+35℃ 700 hPa ~1060 hPa Optional Accessories Bracket set for installation on compatible Charder Infant Scale Standard Accessories User manual x1...
  • Page 21 Notes __________________________________________________________________________________ __________________________________________________________________________________ __________________________________________________________________________________ __________________________________________________________________________________ __________________________________________________________________________________ __________________________________________________________________________________ __________________________________________________________________________________ __________________________________________________________________________________ __________________________________________________________________________________ __________________________________________________________________________________ __________________________________________________________________________________ __________________________________________________________________________________ __________________________________________________________________________________ __________________________________________________________________________________ __________________________________________________________________________________...
  • Page 22 Notes __________________________________________________________________________________ __________________________________________________________________________________ __________________________________________________________________________________ __________________________________________________________________________________ __________________________________________________________________________________ __________________________________________________________________________________ __________________________________________________________________________________ __________________________________________________________________________________ __________________________________________________________________________________ __________________________________________________________________________________ __________________________________________________________________________________ __________________________________________________________________________________ __________________________________________________________________________________ __________________________________________________________________________________ __________________________________________________________________________________...
  • Page 23 Notes __________________________________________________________________________________ __________________________________________________________________________________ __________________________________________________________________________________ __________________________________________________________________________________ __________________________________________________________________________________ __________________________________________________________________________________ __________________________________________________________________________________ __________________________________________________________________________________ __________________________________________________________________________________ __________________________________________________________________________________ __________________________________________________________________________________ __________________________________________________________________________________ __________________________________________________________________________________ __________________________________________________________________________________ __________________________________________________________________________________...
  • Page 24: Declaration Of Conformity

    VII. Declaration of Conformity This product has been manufactured in accordance with the harmonized European standards, following the provisions of the below stated directives: (EU) 2017/745 Regulation on Medical Devices 2014/31/EU Non-automatic Weighing Instruments Directive (OIML models only) RoHS Directive 2011/65/EU and Delegated Directive (EU) 2015/863 Radio Equipment Directive 2014/53/EU (applicable if wireless module is used)
