- Page 1 Height Measurement USER MANUAL HM80M Infant Stadiometer Please keep the instruction manual at hand all the time for future reference.
-
Page 2: Table Of Contents
CONTENTS Explanation of Text/Symbols on Device Label/Packaging 3 Copyright Notice ............. 5 I. Safety Notes ............6 II. Installation ............10 III. Using Device ............ 17 IV.Product Specifications .......... 18 V.Declaration of Conformity ........20... -
Page 3: Explanation Of Text/Symbols On Device Label/Packaging
Explanation of Text/Symbols on Device Label/Packaging Text/Symbol Meaning Caution, consult accompanying documents before use Separate collection for waste of electrical and electronic equipment, in accordance with Directive 2002/96/EC. Do not dispose of device with everyday waste Name and address of device manufacturer, and year/country of manufacture Carefully read user manual before installation and usage, and follow instructions for use. - Page 4 Device complies with EC directives (verified models only) M: Conformity label in compliance with Directive 2014/31/EU for non-automatic weighing instruments 20: Year in which conformity verification was performed and the CE label was applied. (ex: 16=2016) 0122: Identifier for metrology Notified Body Device is a Class III scale in compliance with Directive 2014/31/EU (verified models only) Name and address of entity importing device (if applicable)
-
Page 5: Copyright Notice
Copyright© Charder Electronic Co., Ltd. All rights reserved. This user manual is protected by international copyright law. All content is licensed, and usage is subject to written authorization from Charder Electronic Co., Ltd. (hereinafter Charder) Charder is not liable for any damage caused by a failure to adhere to requirements stated in this manual. -
Page 6: Safety Notes
I. Safety Notes General Information Thank you for choosing this Charder Medical device. It is designed to be easy and straightforward to operate, but if you encounter any problems not addressed in this manual, please contact your local Charder service partner. -
Page 7: General Handling
- To be able to read at a high-school level and understand Arabic numerals (e.g. 1, 2, 3, 4...) - Basic hygiene knowledge - Trained in device's operation - Read the instruction manual (c) Language - Able to read the language of instruction manual and on-screen instructions (d) Qualifications - No special certifications or qualifications required... -
Page 8: Safety Instructions
Cleaning Device surface should be cleaned using alcohol-based wipes. Maintenance Please contact your local Charder distributor for regular maintenance and calibration, regular checking of accuracy is recommended; frequency to be determined by level of use and state of device. Warranty/Liability The period of warranty shall be eighteen(18) months, ... -
Page 9: Incident Reporting
All maintenance, technicalinspections, and repairs should be conducted by an authorized Charder service partner, using original Charder accessories and spare parts. Charder is not liable for any damages arising from improper maintenance or usage. Dismantlement of the device will void the warranty. -
Page 10: Installation
II. Installation A. Attaching head stopper If head stopper is loose, please assemble as seen below:... - Page 11 B. Assembly with Infant Scale (removable measurement tray) 1. Attach bracket to tray using bracket screws*2 SS-5611 bracket 2. Slide HM80M onto bracket, and press buckle to secure...
- Page 12 C. Assembly with MS5900 Infant Scale 1. Remove bracket holder cover. 2. Attach bracket to device with two screws.
- Page 13 3. Attach height rod to bracket carefully until a click noise is heard. (HM80D used as example, same procedure for HM80M) 4. Install bracket holder cover.
- Page 14 5. Disassembling height rod Locate buckle at bottom of height rod. Press down on buckle and slid out height rod.
- Page 15 D. Assembly with MS2400 Infant Scale 1. Attach bracket to device, and fasten screws using screwdriver. Version with rubber head pad rubber head Attach bracket here rubber head Version without rubber head pad Attach bracket here...
- Page 16 2. Connect height measure attachment (HM80D or HM80M) to bracket. A clicking noise will be heard. 3. To detach height measure, find the latch located at the rear of the attachment. Press down on the buckle, and gently remove the attachment from bracket.
-
Page 17: Using Device
III. Using Device A. Performing measurement 1. Lay infant on flat platform, with head touching head stopper.Straighteninfant’sfeet. 2. Use right hand to push foot stopper until it touches soles of infant's feet. Read measurement result. -
Page 18: Iv.product Specifications
1/16 in ± 10 mm Accuracy 870(W) x 290(D) x 70(H) Overall Dimensions Device 0.5 kg Weight +5℃~+35℃ Operation Environment 700 hPa ~1060 hPa Bracket set for installation Optional Accessories on compatible Charder Infant Scale User manual x1 Standard Accessories... - Page 19 Notes ______________________________________________ ______________________________________________ ______________________________________________ ______________________________________________ ______________________________________________ ______________________________________________ ______________________________________________ ______________________________________________ ______________________________________________ ______________________________________________ ______________________________________________ ______________________________________________ ______________________________________________ ______________________________________________ ______________________________________________ ______________________________________________ ______________________________________________ ______________________________________________...
-
Page 20: V.declaration Of Conformity
V.Declaration of Conformity This product has been manufactured in accordance with the harmonized European standards, following the provisions of the below stated directives: (EU) 2017/745 Regulation on Medical Devices 2014/31/EU Non-automatic Weighing Instruments Directive (OIML models only) RoHS Directive 2011/65/EU and Delegated Directive (EU) 2015/863 Radio Equipment Directive 2014/53/EU (applicable if wireless module is used)
