Charder HM130D User Manual

Digital stadiometer, height measurement

Advertisement

Quick Links

Height Measurement
USER MANUAL
HM130D
Digital Stadiometer
Please keep the instruction manual at hand and follow instruction for use.
1

Advertisement

Table of Contents
loading
Need help?

Need help?

Do you have a question about the HM130D and is the answer not in the manual?

Questions and answers

Summary of Contents for Charder HM130D

  • Page 1 Height Measurement USER MANUAL HM130D Digital Stadiometer Please keep the instruction manual at hand and follow instruction for use.
  • Page 3: Table Of Contents

    CONTENTS I. Explanation of Graphic Symbols on Label/Packaging 4 II. Copyright Notice ..........6 III. Safety Notes ............ 7 B. EMC Guidance and Manufacturer's Declaration ..10 IV. Installation ............5 V. Using Device ............6 VI. Product Specifications ........7 VII.
  • Page 4: Explanation Of Graphic Symbols On Label/Packaging

    I. Explanation of Graphic Symbols on Label/Packaging Text/Symbol Meaning Caution, consult accompanying documents before use Separate collection for waste of electrical and electronic equipment, in accordance with Directive 2002/96/EC. Do not dispose of device with everyday waste Name and address of device manufacturer, and year/country of manufacture Carefully read user manual before installation and usage, and follow instructions for use.
  • Page 5 Device complies with EC directives (verified models only) M: Conformity label in compliance with Directive 2014/31/EU for non-automatic weighing instruments 20: Year in which conformity verification was performed and the CE label was applied. (ex: 16=2016) 0122: Identifier for metrology Notified Body Device is a Class III scale in compliance with Directive 2014/31/EU (verified models only) Name and address of entity importing device (if...
  • Page 6: Copyright Notice

    Charder Electronic Co., Ltd. (hereinafter Charder) Charder is not liable for any damage caused by a failure to adhere to requirements stated in this manual. Charder reserves the right to correct misprints in the manual without prior notice, and modify the exterior of the device for quality purposes without customer consent.
  • Page 7: Safety Notes

    III. Safety Notes A.General Information Thank you for choosing this Charder Medical device. It is designed to be easy and straightforward to operate, but if you encounter any problems not addressed in this manual, please contact your local Charder service partner.
  • Page 8 - Able to read the language of instruction manual and on- screen instructions (d) Qualifications - No special certifications or qualifications required Residual Risk evaluation (a) All foreseeable risks have been evaluated and considered acceptable. Generally speaking, the most likely risk caused by incorrect usage of the device is less accurate measurement (or inability to use device to acquire measurement), which does not pose imminent physical risk...
  • Page 9: Maintenance

    Charder service partner, using original Charder accessories and spare parts. Charder is not liable for any damages arising from improper maintenance or usage. Dismantlement of the device will void the warranty.
  • Page 10: Emc Guidance And Manufacturer's Declaration

    B. EMC Guidance and Manufacturer's Declaration Guidance and manufacturer’s declaration-electromagnetic emissions The product isintended for use in the electromagnetic environment specified below. The customer or the user of the product should assure that it is used in such an environment. Emission test Compliance Electromagnetic...
  • Page 11 Guidance and manufacturer’s declaration-electromagnetic immunity The product is intended for use in the electromagnetic environment specified below. The customer or the user of the product should assure that it is used in such an environment. Immunity IEC 60601 Compliance Electroma test level test level...
  • Page 12 Power 30 A/m 30 A/m The product frequency(50, power 60 Hz) frequency magnetic field magnetic IEC 61000-4-8 fields should be at levels characteristi c of a typical location in a typical commercial hospitalenvir onment. NOTE UT is the a.c. mains voltage prior to application of the testlevel. Guidance and manufacturer’s declaration-electromagnetic immunity Theproduct is intended for use in the electromagnetic environment specified below.
  • Page 13 separation distance in metres (m). Field strengths from fixed RF transmitters, as determined by an electromagnetic site survey, should be less than the compliance level in each frequency range. Interference may occur in the vicinity of equipment marked with the following symbol: NOTE1 At 80 MHz and 800 MHz, the higher frequency rangeapplies.
  • Page 14 Recommended separation distance between portable and mobile RF communications equipment and the product The product is intended for use in an electromagnetic environment in which radiated RF disturbances are controlled. The customer or the user of the product can help preventelectromagnetic interference by maintaining a minimum distance between portable and mobile RF communications equipment (transmitters) and the product as recommended below, according to the maximumoutput power of the communications...
  • Page 15: Installation

    IV. Installation Secure excess cable to column Plug data transmission port into indicator...
  • Page 16: Using Device

    V. Using Device 1. Ensure compatible Charder weighing scale is plugged into indicator. 2. Before using HM130D, slide measurement rod down completely then turn on scale to finish calibration(Fig. 1).Height measurement result will automatically be sent to device indicator if connected.
  • Page 17: Product Specifications

    VI. Product Specifications Model HM130D Height Range 75-130 cm Measurement Graduation 0.1 cm 50 (W) x 280 (D) x 1330 Overall (H) mm Device 0.6kg Weight Transmission cable Data Transmission NOTE : Device should be connected to network by qualified distributors only.
  • Page 18 Notes ________________________________________________ ________________________________________________ ________________________________________________ ________________________________________________ ________________________________________________ ________________________________________________ ________________________________________________ ________________________________________________ ________________________________________________ ________________________________________________ ________________________________________________ ________________________________________________ ________________________________________________ ________________________________________________ ________________________________________________ ________________________________________________ ________________________________________________ ________________________________________________ ________________________________________________...
  • Page 19 Notes ________________________________________________ ________________________________________________ ________________________________________________ ________________________________________________ ________________________________________________ ________________________________________________ ________________________________________________ ________________________________________________ ________________________________________________ ________________________________________________ ________________________________________________ ________________________________________________ ________________________________________________ ________________________________________________ ________________________________________________ ________________________________________________ ________________________________________________ ________________________________________________ ________________________________________________...
  • Page 20: Declaration Of Conformity

    VII. Declaration of Conformity This product has been manufactured in accordance with the harmonized European standards, following the provisions of the below stated directives: (EU) 2017/745 Regulation on Medical Devices 2014/31/EU Non-automatic Weighing Instruments Directive (OIML models only) RoHS Directive 2011/65/EU and Delegated Directive (EU) 2015/863 Radio Equipment Directive 2014/53/EU (applicable if wireless module is used)
