Instruction Manual FLEXI-FLOW™ Compact
Bronkhorst®
FF-annS (with integrated shut-off valve)
1. Fluid inlet
2. Support interface (USB-C)
3. Address selector
4. Power and signal connector (9-pin D-sub)
5. Status LED (controller)
6. Control valve
7. Status LED (shut-off valve)
8. Shut-off valve
9. Fluid outlet
FF-annS with Ethernet interface
1. Fluid inlet
2. Support interface (USB-C)
3. Ethernet interface
4. Power and signal connector (9-pin D-sub)
5. Status LED (controller)
6. Address selectors
7. Status LED 9 (shut-off valve)
8. Control valve
9. Shut-off valve
10. Fluid outlet
