Actuator Type
Type
Unsigned char
This parameter sets the operating mode of the selected valve. Make sure the operating mode matches the shut-off valve
function (N.C. or N.O.), otherwise the the shut-off valve will close when the control valve is open and vice versa.
Supported values:
Value Operating mode
5 Manual, N.C.
6 Manual, N.O.
7 Automatic, N.C.
8 Automatic, N.O.
255 Disabled
IO Switch Status
Type
Unsigned long
This parameter actuates the shut-off valve, but only if its operating mode is set to Manual (parameter Actuator Type). Depending
on the valve type, actuation opens or closes it:
Actuation Normally Normally
open closed
Inactive open closed
Active closed open
The value of IO Switch Status is a bitwise summation of 2 function settings; convert the decimal value to binary to see the status
of each bit. To activate one or both bits, write the sum of their decimal (or hex) values to the register.
Parameter IO Switch Status supports the following settings (other bits are ignored):
Bit Function
0 Actuation switch
8 Observe or ignore
instrument safe state*
*) See parameter Special parameters - Control Mode
Immediately after powering-up, both bits are inactive.
·
· In the event of communication faults, the shut-off valve will assume its
bit 8).
4.3.8 Device identification
User Tag
Type
Unsigned char[16]
With this parameter, the instrument can be given a custom tag name, with a maximum of 16 characters.
9.17.158G
Access Range
RW See below
Access Range
RW See below
Value Description
0 Valve inactive (not powered)
1 Valve active (powered)
0 Observe default/safe state; actuation disabled if the instrument is in
default/safe state.
256 Ignore default/safe state; shut-off valve actuation enabled even if the
instrument is in default/safe state.
Access Range
RW -
