Default settings
Network configuration is done ex factory as ordered. The table below shows the supported settings for the available
communication protocols.
Notes:
· Default settings are printed in bold.
· The node address can only be set by means of the digital parameters for the communication protocols for which default
values are indicated. For other communication protocols, use the address selectors on the instrument (see
settings (Ethernet) ).
19
Protocol
Address
Baud Rate
Parity
4.3.4.2 IP address settings
· After changing IP address settings, restart the instrument to apply the changes.
For protocol specific address settings, refer to the
·
Fieldbus1 IP Address
Type
String
Fieldbus1 Subnet Mask
Type
String
Fieldbus1 Gateway Address
Type
String
4.3.5 Fluid set
Fluid Set Index
Type
Unsigned char
With this parameter, any of the pre-configured fluids (up to 8) can be selected. Each fluid has its specific (configurable)
properties, such as Fluid Name, Capacity, etc.
Default value: 0 (fluid 1).
Note that the selected value is equal to the fluid number minus 1 (value 0 corresponds to fluid 1, value 1 to fluid 2, etc.)
Fluid Name
Type
Unsigned char[10]
This parameter contains the name of the selected fluid.
