Event details
Diagnostic event data is stored in a matrix, where each row represents 1 event, identified by an index.
·
· The event matrix has a maximum size of 50 rows and is updated cyclically.
· Setting Diagnostic Event Index to the required value populates the other parameters with the associated event data.
Name
Diagnostic Newest Event Index
Index of the most recently added
event
Refers to Diagnostic Event Index
Diagnostic Event Index
Unique row identifier
Diagnostic Event Code
Diagnostic Event Description
Diagnostic Event Active
Is the event still applicable?
Updated if the cause of the event has
been eliminated
Diagnostic Event NAMUR Status
Instrument status at the time of event
occurrence
Diagnostic Event Timestamp
*) numbers in square brackets indicate the number of blocks/registers occupied by a parameter.
Value ranges
Parameter Value
Diagnostic Event Active 0
1
NAMUR Status 0
(also see section
1
Instrument status )
18
2
4
8
4.3.12 Special parameters
Init Reset
Type
Unsigned char
Init Reset is used to unlock secured parameters (marked with a
Value Description
64 unlocked, secured parameters can be read and written to
82 locked, secured parameters are read-only
At power-up, Init Reset is always set to 'Locked' (value 82).
Reset
Type
Unsigned char
This parameter is used to reset the program, counter or alarms (alarms are reset on all channels).
9.17.158G
Type
Unsigned int
Unsigned int
Unsigned int
String
Unsigned char
Unsigned char
Unsigned long
Description
false
true
Normal operation
Maintenance required
Out of specification
Check function
Failure
Access Range
RW 82/64
Access Range
R 0...7
Instruction Manual FLEXI-FLOW™ Compact
Bronkhorst®
Access Range
R 0...49
RW 0...49
R
R
R see below
R see below
R
FlowDDE ProPar
7 0/10
B
symbol) for writing. It supports the following values:
FlowDDE ProPar
114 115/8
FlowDDE ProPar Modbus*
411 118/14 0x0ECE/3791 [1]
412 118/15 0x0ECF/3792 [1]
413 118/16 0x0ED0/3793 [1]
414 118/20 0xF6A0/63137 [8]
415 118/17 0x0ED1/3794 [1]
416 118/18 0x0ED2/3795 [1]
417 118/21 0xF6A8/63145 [2]
Modbus
0x000A/11
Modbus
0x0E68/3689
