  • Page 1 Quick Start Guide for mass flow meter & controller FLEXI-FLOW™ Compact FF-A2xx, FF-A5xx, FF-S2xx, FF-S5xx FF-M0x, FF-C0x, FF-A0xx FF-M1x(D), FF-C1x(D) IMPORTANT! Read carefully before use. Keep for future reference.

  • Page 2: Safety First

    ▶ If in any doubt: scan the QR code (Service & Support) on the The product requires professional experience and knowledge of back cover to get in contact with Bronkhorst. installation, operational requirements of the relevant industry, and knowledge of the type of application and national requirements ▶...

  • Page 3: Process Fluid

    ▶ If in any doubt: scan the QR code (Service & Support) on the product in a non-critical process. It guides the user in controlling back cover to get in contact with Bronkhorst. and monitoring research and pilot setups by means of The user is responsible for taking the necessary safety measures Bronkhorst FlowSuite.
  • Page 4 FLEXI-FLOW™ Compact FF-xxx 1. Fluid inlet 5. Status LED 2. USB-C port 6. Control valve (only MFC) 3. Address selector 7. Serial number label 4. Connector 8. Fluid outlet...
  • Page 5 FLEXI-FLOW™ Compact FF-xxxD 1. Fluid inlet 5. Status LED 2. USB-C port 6. Control valve (only MFC) 3. Address selector 7. Serial number label 4. Connector 8. Fluid outlet...
  • Page 6 FLEXI-FLOW™ Compact FF-xxx (ethernet) 1. Fluid inlet 5. Status LED 9. Fluid outlet 2. USB-C port 6. Address selectors 3. Ethernet ports 7. Control valve (only MFC) 4. Connector 8. Serial number label...

  • Page 7: Before Installation

    5. Not connected ▶ Scan the QR code (Service & Support) on the back cover. 6. D1 Modbus (B/B’) or RS485-A ▶ Go to the Bronkhorst website and select your operating 7. +Us (24 Vdc) system to download Bronkhorst FlowSuite. For download 8.

  • Page 8: Pressure Rating

    Mounting location (general) To ensure reliable measurements, it is important to choose a correct mounting location. For optimal performance, observe the following guidelines: ▶ Install the product on a flat, rigid, and clean surface [1]. ▶ Avoid installation close to mechanical vibrations [2]. ▶...
  • Page 9 Mounting FF-C1xD CAUTION Risk of personal injury due to fluid leakage! Incorrect mounting can lead to fluid leakage and severe injury. ▶ Only use supplied seals for mounting. ▶ Check all connections for fluid leakage before and after applying fluid pressure. The product comes with bolts and seals for mounting.

  • Page 10: Electrical Connection

    Fluid line connection Electrical connection For basic setup, it is recommended to use Bronkhorst® CAUTION accessories (not included) as described in this manual. Risk of personal injury due to fluid leakage! ▶ Ensure all address selectors on the product are set to ‘0’ (zero).

  • Page 11: Adjusting Zero Point

    Adding the product to Bronkhorst FlowSuite When Bronkhorst FlowSuite is started, the software will automatically search for connected instruments. All found instruments are displayed in the left pane. ▶ Use the refresh option to check for newly connected products. Commissioning ▶...

  • Page 12: Bluetooth Functionality

    Product status in Bronkhorst FlowSuite The product has Bluetooth, this is disabled by default. To monitor In Bronkhorst FlowSuite, an icon is displayed next to the product the process using a smartphone, Bluetooth must first be activated. in the left pane. The icon indicates the status of the product. When selecting a product from the left pane, more status information is given in the overview screen.

  • Page 13: Maintenance

    ▶ Purge the fluid path with a clean, dry and inert gas. For information about Bronkhorst® and worldwide service Replacing seals addresses, please visit our website. If a downported product has been removed from the application, ▶...
  • Page 14 (WEEE). Max. install. altitude m (ft) 2000 (6560) Bronkhorst will take care of proper dismantling, recycling and/or reuse. By ensuring this product is disposed of Warm-up time min. correctly, you will help prevent potential negative consequences...

  • Page 15: Declaration Of Conformity

    © 2024 Bronkhorst High-Tech B.V. - All rights reserved case the user will be required to correct the interference at his own Bronkhorst® is a registered trademark. All trademarks are the property of expense. their respective owners.
  • Page 16 Bronkhorst High-Tech B.V. +31 573 45 88 00 Nijverheidsstraat 1a info@bronkhorst.com NL-7261 AK Ruurlo, The Netherlands www.bronkhorst.com Service & Support Bronkhorst FlowSuite Product Info 9.17.182A • 2024-01...
