- Page 1 FLEXI-FLOW™ Compact FLEXI-FLOW™ Compact Mass Flow & Pressure Meter/Controller Mass Flow & Pressure Meter/Controller with TCS Technology with TCS Technology Quick Start Guide Quick Start Guide English English Doc. no.: 9.17.157 rev. A Doc. no.: 9.17.157 r Date: 29-03-2022 Date: 29-03-2022...
-
Page 2: Complete Documentation
Complete documentation For a comprehensive instruction manual, hook-up diagrams and other applicable documentation about the FLEXI-FLOW™ Compact, visit the Bronkhorst® product pages: www.bronkhorst.com/flexi-flow (or scan the QR code) Intended use The FLEXI-FLOW™ Compact has been developed to measure and/or control mass flow rates and pressures of clean, dry, non-corrosive and non-toxic gases in a fluid system. -
Page 3: Product Overview
Product overview 1. Power & signal connector (9-pin D-sub) 2. Address selection switch 3. Service port (USB-C) 4. Fluid inlet 5. Status indication LED 6. Control valve 7. Fluid outlet 8. Flow direction Installation RS-485 D0 (A/A') Not connected Not connected 0 Vs Not connected RS-485 D1 (B/B') -
Page 4: Digital Configuration
Configuration Set instrument address Digital configuration 0: digital parameter setting After installing FlowSuite, establish 1-9: set manually (overrides the digital connection through service port (USB-C) parameter) Configure with FlowSuite Install FlowSuite bronkhorst-flowsuite bronkhorst-flowsuite... - Page 5 Powering up Check leak tightness of fluid system before applying full operating pressure · For reliable operation, make sure fluid stream is uncontaminated. · 1. Power up 2. Pressurize fluid system 3. Green indication LED: ready to use!
-
Page 6: Customer Care
(or scan the QR code) Disposal If you are a customer within the European Union and wish to dispose of Bronkhorst® equipment bearing the symbol of a crossed out waste disposal bin, Bronkhorst can take care of proper dismantling, recycling and/or reuse. Just return the item(s) following the return instructions on our website;...
