- Page 1 Quick Start Guide for mass flow meter & controller LOW-ΔP-FLOW F-10xD, F-10xE, F-201DS F-20xDV, F-201ES, F-20xEV IMPORTANT! Read carefully before use. Keep for future reference.
-
Page 2: Safety First
▶ If in any doubt: scan the QR code (Service & Support) on the The product requires professional experience and knowledge of back cover to get in contact with Bronkhorst. installation, operational requirements of the relevant industry, and knowledge of the type of application and national requirements ▶... -
Page 3: Process Fluid
▶ If in any doubt: scan the QR code (Service & Support) on the in a non-critical process. It will guide the user in controlling and back cover to get in contact with Bronkhorst. monitoring research and pilot setups using Bronkhorst FlowSuite The user is responsible for taking the necessary safety measures software. - Page 4 FLOW FLOW LOW-ΔP-FLOW 1. Fluid inlet 5. Switch/Push button 9. Serial number label 2. Address selector (MSD) 6. Status LEDs 10. Fluid outlet 3. Address selector (LSD) 7. Connector 4. Connector (optional) 8. Control valve...
- Page 5 FLOW FLOW LOW-ΔP-FLOW with integrated shut-off valve 1. Fluid inlet 5. Switch/Push button 9. Shut-off valve 2. Address selector (MSD) 6. Status LEDs 10. Fluid outlet 3. Address selector (LSD) 7. Connector 11. Serial number label 4. Connector (optional) 8. Control valve...
-
Page 6: Before Installation
5. Custom* ▶ Scan the QR code (Service & Support) on the back cover. 6. RX-RS232/BUS ▶ Go to the Bronkhorst website and select your operating 7. +Us (15 ... 24 Vdc) system to download Bronkhorst FlowSuite. For download 8. 0 V sense information, see the back cover of this manual. -
Page 7: Mounting Location
Mounting location To ensure reliable measurements, it is important to choose a correct mounting location. For optimal performance, observe the following guidelines: ▶ Install the product on a flat, rigid, and clean surface [1]. ▶ Avoid installation close to mechanical vibrations [2]. ▶... -
Page 8: Electrical Connection
Fluid line connection Electrical connection For basic setup, it is recommended to use Bronkhorst® CAUTION accessories (not included) as described in this manual. Risk of personal injury due to fluid leakage! ▶ Ensure all address selectors on the product are set to ‘0’ (zero). -
Page 9: Adjusting Zero Point
Adding the product to Bronkhorst FlowSuite When Bronkhorst FlowSuite is started, the software will automatically search for connected instruments. All found instruments are displayed in the left pane. ▶ Use the refresh option to check for newly connected products. If the product is not found, it may not be set to serial RS-232. - Page 10 Product status in Bronkhorst FlowSuite If a connection between the product and Bronkhorst FlowSuite In Bronkhorst FlowSuite, an icon is displayed next to the product cannot be established, the switch/push button can be used to in the left pane. The icon indicates the status of the product. When...
-
Page 11: Maintenance
Maintenance Technical specifications Although no routine maintenance is required, to ensure that the Description Unit Value product works correctly and safely, a regular (visual) inspection is Maximum fluid pressure bar(g) See serial number recommended. label Check prior to each use Permissible fluid temp. -
Page 12: Service And Support
(WEEE). Bronkhorst representative. Bronkhorst will take care of proper dismantling, recycling ▶ To help you quickly, make sure you have the serial number of and/or reuse. By ensuring this product is disposed of the product at hand. -
Page 13: Declaration Of Conformity
The full text of the applicable declarations of conformity are available at the following web address: https://www.bronkhorst.com/int/downloads-1. © 2024 Bronkhorst High-Tech B.V. - All rights reserved Bronkhorst® is a registered trademark. All trademarks are the property of their respective owners. - Page 16 Bronkhorst High-Tech B.V. +31 573 45 88 00 Nijverheidsstraat 1a info@bronkhorst.com NL-7261 AK Ruurlo, The Netherlands www.bronkhorst.com Service & Support Bronkhorst FlowSuite Product Info 9.17.185A • 2024-02...
