Fieldbus1 Selection
Type
Unsigned char
· Selected communication protocol on the power and signal connector.
· Changes are effective immediately.
The instrument only accepts values that match its hardware configuration (Ethernet/non-Ethernet, see table below).
·
· Default value (ex factory)
o non-Ethernet: 1
o Ethernet: 14
Available protocols:
Value Description
0 FLOW-BUS
1 Modbus RTU
2 ProPar
11 EtherCAT®
14 PROFINET
18 POWERLINK
19 EtherNet/IP™
20 Modbus TCP
4.3.4.1 Node address settings
On instruments with no Ethernet interface, setting the
·
overrides the digital node address setting.
· Changes made to the node address settings will not be restored by a factory reset.
Although each
·
of the FLEXI-FLOW have the same node address.
· For protocol specific address settings, refer to the
Fieldbus1 Address
Type
Unsigned char
Fieldbus1 Baud Rate
Type
Unsigned long
Fieldbus1 Parity
Type
Unsigned char
The following values are supported:
Value Description
0 No parity
1 Odd parity
2 Even parity
9.17.158G
Access Range
B
RW [0...2]
communication channel
Access Range
B
RW 0...255
Access Range
B
RW 0...1.0E10
Access Range
B
RW 0...2
Instruction Manual FLEXI-FLOW™ Compact
Bronkhorst®
FlowDDE ProPar
305 125/8
manual address selector
represents an individual instrument, all three communication channels
21
manual for the respective communication protocol
FlowDDE ProPar
199 125/10
FlowDDE ProPar
201 125/9
FlowDDE ProPar
335 125/12
Modbus
0x0FA8/4009
Non- Ethernet
Ethernet
ü
ü
ü
to a value other than 0
8
.
11
Modbus
0x0FAA/4011
Modbus
0xFD48...0xFD49/64841...64842
Modbus
0x0FAC/4013
ü
ü
ü
ü
ü
