7 Troubleshooting

7.3 Inconsistency Problems

The size of the preview and the mark is inconsistent with the software display, or the preview
and the mark are not horizontal or vertical but slanted.
• Check and fix the parameters. See
• If the problem remains, fix the parameters.
a. Select Parameter (F3) → Field.
b. Input numbers in Offset X, Offset Y or Angle according to the actual deviation number
based on the measurement with a ruler.
c. Exit after confirming.
• If the problem remains, contact our customer service.
§4.5.4 Configuring Parameters
2
3
4
OK Cancel
1
59
on Page 29.
Apply
