Omtech LYF-175S User Manual page 43

Loading Vector Graphics
1. Click to draw a vector file.
2. Choose the file folder.
3. Select the file type.
4. Select the image to be marked.
5. Open the image and import
the canvas.
6. Set vector graph parameters.
a. Select the picture.
b. Center the vector graphics on the canvas.
If the image is outside the canvas, select the image and click in the center of the canvas to
find the image.
c. Set the vector file parameters.
d. After setting the graphic size, click Apply.
e. Click to fill in the settings and click OK after completing the settings.
f. Set processing parameters: speed, power, frequency.
See § Setting Engraving Parameters
1
e
b
c
d
on Page 39 for details.
38
2
4
5
3
a
f
