4 Installation

4.5.4 Configuring Parameters

1. Click File → System parameter to check and make sure the Workspace settings are the same
as that on the picture "File_system Parameter_workspace.jpg" in the USB drive.
2. If the rotary axis is used, click Laser → Rotate TextMark to check and make sure the rotary
settings are the same as that on the picture "Laser-Rotate TextMark-param.jpg" in the USB
drive.
3. Click Param (F3) to check and make sure the settings on each subpage are the same as that on
the picture "Parameter-Field.jpg", "Parameter-Laser Control.jpg", "Parameter-Other-Red light
pointer.jpg", and "Parameter-Port.jpg" in the USB drive.
