USER'S MANUAL
AC DIELECTRIC TEST SET
600 SERIES
Model Number BK130/36
VERSION 6.2
Phenix Technologies, Inc
.
75 Speicher Drive
Accident, Maryland 21520
Copyright © Phenix Technologies, Inc.
Rev 6/12/2017
Rev Install Warning 2/13/2018
BK130/36

Advertisement

Table of Contents
loading
Need help?

Need help?

Do you have a question about the BK130-B and is the answer not in the manual?

Questions and answers

Subscribe to Our Youtube Channel

Related Manuals for Phenix Technologies BK130-B

Summary of Contents for Phenix Technologies BK130-B

  • Page 1 USER’S MANUAL AC DIELECTRIC TEST SET 600 SERIES Model Number BK130/36 VERSION 6.2 Phenix Technologies, Inc 75 Speicher Drive Accident, Maryland 21520 Copyright © Phenix Technologies, Inc. Rev 6/12/2017 Rev Install Warning 2/13/2018 BK130/36...

  • Page 2: Table Of Contents

    TABLE OF CONTENTS DESCRIPTION SECTION NUMBER DANGER / GENERAL SAFETY PRECAUTIONS TECHNICAL SPECIFICATIONS UNCRATING PROCEDURE CONTROLS AND INDICATORS INITIAL SET-UP--MECHANICAL/ELECTRICAL OPERATIONAL VERIFICATION / GENERAL TEST GROUND/GUARD/RETURN CONNECTIONS CALIBRATION TROUBLESHOOTING MECHANICAL MAINTENANCE CHECKING OIL PURITY/SPECIFICATIONS TRANSPORTING/STORAGE OF EQUIPMENT CIRCUIT DIAGRAM SYMBOLS ELECTRICAL DIAGRAMS PARTS ORDERING INFORMATION RECOMMENDED SPARE PARTS...
  • Page 3 WARNING !! Complete Grounding of this unit is necessary for the safe operation of this equipment. Disconnect inputs before ungrounding this equipment BK130/36...

  • Page 4: General Safety Precautions

     DO NOT operate damaged equipment. Remove power, and do not use the equipment until safe operation can be verified by service-trained personnel. Phenix Technologies, Inc. assumes no liability for unsafe or improper use of test equipment. BK130/36...

  • Page 5: Section 1: Technical Specifications

    SECTION 1: TECHNICAL SPECIFICATIONS Input 110 -120 volts, single phase 50 / 60 Hz, 30 amperes 208- 240 volts, single phase 50 / 60 Hz, 15 Amperes (Refer to Serial Tag for voltage and current designation) Output Rating 0-36 kilovolts, 180 milliamperes 0-130 kilovolts, 50 milliamperes Duty Cycle –...

  • Page 6: Section 2: Uncrating Procedure

    SECTION 2: UNCRATING PROCEDURE 1. Exercise care in removing shipping materials so as not to damage unit. 2. Perform visual inspection to determine if unit was damaged during shipment. If there are any signs of physical damage (such as dents, scratches, oil leaks), contact the factory before proceeding.

  • Page 7: Section 3: Controls And Indicators

    SECTION 3: CONTROLS AND INDICATORS Control Section FIGURE 3-1 BK130/36...
  • Page 8 CONTROLS AND INDICATORS Descriptions are keyed to Figure 3-1. Main Power Indicator. Main Power Circuit Breaker. Interrupts all power into set. F1 (120V) F1,2 (220V) - Control Power Fuse/Fuses. Transformer Power Circuit Breaker - Interrupts power to HV Transformer. Breaker must be on to activate High Voltage.
  • Page 9 CONTROLS AND INDICATORS FIGURE 3-2                BK130/36...
  • Page 10 CONTROLS AND INDICATORS High Voltage Section Descriptions are keyed to Figure 3-2. Power Connector – Power Cable from Output to Transformer connector, connects here. High Voltage Unit Ground Point - A Ground cable from facility ground or earth ground must be connected here.

  • Page 11: Section 4: Initial Set-Up-Mechanical / Electrical

    SECTION 4: INITIAL SET-UP—MECHANICAL / ELECTRICAL WARNING ! DO NOT OPERATE THE TEST SET WITHOUT REMOVING HIGH-VOLTAGE TRANSFORMER FROM THE CART. THE HIGH-VOLTAGE TRANSFORMER MUST BE POSITIONED A SAFE DISTANCE FROM PERSONNEL AND OTHER OBJECTS. BK130/36...
  • Page 12 INITIAL SET-UP—MECHANICAL / ELECTRICAL 1. Set up Bucket Truck or object under test. If testing a Bucket Truck, it is recommended to place outriggers and tires on insulating pads. CAUTION: When setting up the Bucket Truck, ensure that there are no overhead safety hazards such as live power lines.
  • Page 13 INITIAL SET-UP--ELECTRICAL WARNING: Ground the output of the High Voltage Transformer until set-up is complete! Be sure the Main Power Circuit Breaker is in the OFF position before proceeding. This equipment should only be operated by personnel familiar with High Voltage Testing and Safety Procedures. The following are examples of basic setups for performing various tests using the PHENIX test set.
  • Page 14 INITIAL SET-UP—ELECTRICAL (Figure 4-1)  BK130/36...
  • Page 15 INITIAL SET-UP---ELECTRICAL Connections for testing Category C Aerial Devices (REFER TO FIGURE 4-2 1. Connect the ground stud on the high voltage transformer to a good earth ground using the supplied lead. 2. Connect the ground stud on the high voltage transformer to the ground stud on the control cabinet using the supplied lead.
  • Page 16 Initial Setup-- Electrical ( Figure 4-2)  BK130/36...
  • Page 17 INITIAL SET-UP---ELECTRICAL Connections For Testing Chassis Insulators On Aerial Devices (Refer To Figure 4-3) 1. Connect the ground stud on the high voltage transformer to a good earth ground using the supplied lead. 2. Connect the ground stud on the high voltage transformer to the ground stud on the control cabinet using the supplied lead.
  • Page 18 INITIAL SETUP - ELECTRICAL (Figure 4-3)  BK130/36...

  • Page 19: Section 5: Operational Verification Procedure

    SECTION 5: OPERATIONAL VERIFICATION PROCEDURE WARNING This equipment should only be used by personnel familiar with High Voltage Testing and Safety Procedures. 1. Make sure that Main Power Circuit Breaker on the Control Panel is in OFF position. 2. Make sure that all electrical connections have been properly made between the Controls and High Voltage Unit, including grounds.
  • Page 20 OPERATIONAL VERIFICATION PROCEDURE 14. Move short from 36 kV output to 130 kV output and ground. Set Measurement Divider Switch to 36 kV / 180 mA. Repeat step 13. Unit should trip off at approximately 4.6 mA. NOTE: Do not attempt to check 110% level of current trip under shorted output conditions. Rated output currents are only available through a capacitive load of sufficient value.
  • Page 21 GENERAL TEST PROCEDURE 1. Make sure that Main Power Circuit Breaker on the Control Panel is in the OFF position. 2. Make sure that all electrical connections have been properly and securely made, and that the test specimen is properly connected to the High Voltage Transformer (refer to Initial Set-up Procedures). Make sure the Guard / Ground / Return Jumper Clip is set properly for test being performed.

  • Page 22: Section 6: Guard-Ground-Return Connections

    SECTION 6: GUARD-GROUND-RETURN CONNECTIONS The base of the High Voltage transformer contains a currentmeter feature useful in measurement of different current sources. (Refer To Figure 6-1) Standard Mode (RTN) (Use for liner testing) The standard configuration is set up to measure the current from the high potential side of the unit under test to ground.
  • Page 23 GUARD-GROUND-RETURN CONNECTIONS Figure 6-1                           BK130/36...

  • Page 24: Section 7: Calibration

    SECTION 7: CALIBRATION CAUTION Calibration should only be done by persons familiar with High Voltage testing and safety procedures. All calibrations have been done at the factory. Periodic calibration of the output voltmeter and output currentmeter should be done annually. NOTE: Refer to Electrical Diagram Section for schematics pertaining to the model number of your test set.
  • Page 25 CALIBRATION Overcurrent This calibration should not need adjustment (factory adjusted). If the Overcurrent Circuit is out of calibration, perform the following steps. To recalibrate the Overcurrent Circuit with the High Voltage Unit it will be necessary to connect a 15 – 20 nanofarad capacitor rated at 36 kVAC or higher to the 36 kV / 180 mA output of the High Voltage Unit.

  • Page 26: Section 8: Troubleshooting

    Check main facility input power to the test set. Check all control and switch settings. Check indicating lamps. (Spare lamps are available through Phenix Technologies.) Check Fuse F1/F1, F2 Check operation of main power circuit breaker (CB1). Main Power lamp should be on.
  • Page 27 TROUBLESHOOTING Specific Problems (Cont’d) Currentmeter inoperable?  Binding post jumper clip installed between ground and guard with a grounded test object.  Connection between currentmeter and high voltage test specimen return connected improperly.  Meter damaged  Faulty, TX1 interconnect cable. ...

  • Page 28: Section 9: Mechanical Maintenance

    SECTION 9: MECHANICAL MAINTENANCE General No solution or chemical stronger than an ordinary household cleaner should be applied to the cabinet area of this unit. Care must be used when cleaning console panel. Abrasives may remove printing and descriptive titles. When cleaning, always have unit disconnected from power source. Never attempt to clean inside the unit as the cleaning solution may cause damage to the electronic components.

  • Page 29: Section 10: Checking Oil Purity

    SECTION 10: CHECKING OIL PURITY NOTE: Typical test data for the oil used by Phenix Technologies are provided at the end of this section. 1. The most reliable means of determining the purity of the oil in the field is to test the dielectric strength. Test sets for this purpose available on the market differ in design, particularly in the shape of the electrodes and the test container.
  • Page 30 10-2 CHECKING OIL PURITY 4. Oil Specifications Transformer oil is a high quality insulating oil specially refined and formulated to meet the exacting requirements of major electrical equipment manufacturers and users. It also meets Federal Specification VV-I- 530a. High quality mineral-based transformer oil is recommended as the insulating and cooling medium for oil- immersed transformers.
  • Page 31 10-3 CHECKING OIL PURITY Typical Test Data for Transformer Oil TEST METHOD UNITS SPECIFICATION Moisture ASTM D1533 Mg/kg 35 max Color ASTM D1500 ASTM 0.5 max DDF (Power Factor) @100ºC ASTM D924 0.3 max 0.3 max Breakdown voltage (2mm gap) ASTM D1816 35 min Inhibitor Content...

  • Page 32: Section 11: Transporting / Storageof Equipment

    11-1 SECTION 11: TRANSPORTING / STORAGEOF EQUIPMENT In some instances there is a requirement for transporting the equipment from one location to another for on- site field testing. If such conditions prevail, the following precautions should be adhered to. 1. Control Box / Regulator Section Anchor sufficiently to prevent movement during shipment and covered with a canvas or other protective covering to prevent damage during transport.

  • Page 33: Section 12: Circuit Diagram Symbols

    12-1 SECTION 12: CIRCUIT DIAGRAM SYMBOLS CIRCUIT DIAGRAM SYMBOLS SYMBOLES POUR SCHEMA DE CIRCUIT SYMBOLE ZU SCHEMA SYMBOL DESCRIPTION DESCRIPTION BEMENKUNG Amplifier Unite d'amplificateur Verstarker ARSR Surge Arrestor Parafoudre Ueberspannungsableiter Capacitor Condensateur Kondensator BSHG Bushing Tranversee Durchfuehoung Electrolytic Capacitor Condensateur electrol Eleckrolytik kondensator Fuse Fusible...

  • Page 34: Section 13: Electrical Diagrams

    13-1 SECTION 13: ELECTRICAL DIAGRAMS Drawing Number Description  9602130- 120 V BK130/36 Electrical Schematic  9602132- 220-240 V BK130/36 Electrical Schematic BK130/36...

  • Page 35: Section 14: Parts Ordering Information

    When your purchase order is received at our office, a representative of Phenix Technologies will contact you to confirm the current price of the part being ordered. If a part you order has been replaced with a new or improved part, an Applications Engineer will contact you concerning any change in part number.

  • Page 36: Section 15: Recommended Spare Parts

    If the unit will be operated at an isolated site for an extended period or will be subjected to unusual stresses, a larger quantity of parts should be stocked as spares. In such a case, contact your Phenix Technologies' sales representative for a recommendation.

  • Page 37: Section 16: Parts List

    16-1 SECTION 16: PARTS LIST CONTROLS ITEM DESCRIPTION 1601330 30A 1P CKT BRKR 250V (CE) 1601395 CKT BRKR HOLE COVER CB1 (220V) 1601317 15A, 2P, CKT BRKR 240V 1601332 30A 2P CKT BRKR 250V (CE) CB2 (220V) 1601317 15A, 2P, CKT BRKR 240V CON1 1153910 MLX PLG 2P...
  • Page 38 16-2 PARTS LIST CONTROLS ITEM DESCRIPTION 1720201 RESISTOR 1720800 RESISTOR SW10 1860265 LATCHING 2 POLE SWITCH SW10, LP1, LP4 1420163 LED WHITE 24VDC SW10,11 1422153 LENS CLEAR SW11 1860260 LATCHING 1 POLE SWITCH SW2/LP2 1422150 LENS RED SW2-4,LP2-4 1860120 MOM. 1POLE SWITCH SW3/LP3 1422151 LENS, GREEN...
  • Page 39 16-3 PARTS LIST HIGH VOLTAGE SECTION ITEM DESCRIPTION CON-CAPS 1151196 SIZE 17 CAP D3001-4 1780066 10V TRANSORB GROUND-BP 1351103 BINDING POST (GREEN) 459-104 GUARD-BP 1351104 BINDING POST 459 WHITE MOV3001-3 31107000 PCB1070: 3 PC MOVISTOR BD (130V) (2013) MOV3001-3 (220V) 31107001 PCB1070: 3 PC MOVISTOR BD (275V) (2013) P3001 1151178...

  • Page 40: Section 17: Returned Material

    Serial Number Reason for Return Cause of Defect If Phenix Technologies, Inc. deems return of the part appropriate; it will then issue an "Authorization for Return." If return is not deemed advisable, other inspection arrangements will be made. NOTE: Material received at this plant without the proper authorization shall be held as "Customer's Property"...

  • Page 41: Section 18: Customer Comments/Suggestions

    18-1 SECTION 18: CUSTOMER COMMENTS/SUGGESTIONS Phenix Technologies made significant efforts to ensure that the materials in this Operator’s Manual are correct. If there are concerns or comments as you have used this information, Phenix Technologies appreciates any feedback. Unit Serial Number.
