- Page 1 Instruction Guide 12920 Holman Rancho Cordova, CA 95742 800-343-7486 InstallationSupport@Holman.com 20240212R1 DATE: ________________...
-
Page 2: Table Of Contents
7/16” and 1/2" Socket and Wrench #2 Phillips Screwdriver Before You Begin • Read all instructions prior to assembling or installing any Holman product. • Always locate your installation locations prior to performing any work. • ENSURE SAFETY WHILE INSTALLING OR DRILLING INTO VEHICLE. -
Page 3: Parts List
Instructions – 12920 Parts List Hardware For Technical Support Call: 800-343-7486, Monday-Friday, 7AM - 4 PM (PST) Page 2... -
Page 4: Step 1 - Install Lower Stobe Light Brackets And Clamps To Rack
Instructions – 12920 Step 1 – Install Lower Stobe Light Brackets and Clamps to Rack • Using two 5/16 x 1” carriage bolts, two 5/16” flat washer, and two 5/16” lock nuts, bolt through the lower strobe light bracket and strobe light clamp to attach them to any 1” tube on the rack. -
Page 5: Step 3 - Install Lights On The Upper Bracket
Instructions – 12920 Step 3 – Install Lights on the Upper Bracket NOTE: Lights (40424) are not included with this kit and must be purchased separately. • Using two 8-32 pan head screws, two 8 flat washers, and two 8-32 flange lock nuts, attach the light to the upper light bracket as shown.
