Howdens LEAF75TLR Assembly & Installation page 2

6
Carefully stand the unit upright.
Fit the studs to the side panels, then locate the shelf.
Lock the VB cams in place.
Installation
7
Adjust the cabinet to ensure square and
level.
9
Fit the shelves to the cabinet using the shelf pegs.
Shelf Peg x12
HD420192
Cam Stud
x4
x4
A
8
Fit the cabinet to the wall using the L shape
metal brackets.
10
Fit the doors to the cabinet and adjust as required.
See kitchen installation manual for further details.
B
A
Depth
4x30mm
x2
x2
A
C
B C
Side Height
